SA516 Gr.60 / Gr.70, SA537 Cl.1 / Cl.2, P265GH, P355GH, P355NH / NL Pressure Vessel Steel Plate

Excellent notch toughness and reliable impact performance at ambient & low temperature
Strictly controlled internal quality, 100% ultrasonic inspection optional
Good weldability and formability for pressure vessel fabrication
Compliant with ASME & EN standards, full MTC test certificates supplied
Custom cutting, size processing & fast delivery for bulk order

Product Overview

Our SA516 Gr.60 / Gr.70, SA537 Cl.1 / Cl.2, P265GH, P355GH, P355NH / NL pressure vessel steel plates are widely recognized general pressure vessel carbon steel, manufactured to ASME and EN European standards. This series steel is designed for room and moderate low-temperature pressure equipment service.

SA516 series carbon steel plate is the most popular ASME pressure vessel grade, commonly used for welded pressure vessels, storage tanks, heat exchangers. SA537 is normalized carbon-manganese steel with improved toughness for thicker plate applications. P265GH, P355GH, P355NH and P355NL are EN standard boiler & pressure vessel steel grades, widely accepted across European chemical, energy and manufacturing industries.

These steel plates feature stable tensile strength, good ductility and outstanding welding property. All products come with full material test certificates, can perform UT, Charpy V-notch impact test upon request. We provide various thickness, width and length, support flame cutting, plasma cutting and machining according to customer drawings. Typical applications include industrial pressure vessels, chemical processing equipment, oil & gas storage tanks, power plant auxiliary vessels and other pressurized structural components.

Boiler & Pressure Vessel Steel Plate

Chemical & Mechanical Property Snapshot

Grade	C Max(%)	Mn(%)	Si(%)	S Max(%)	P Max(%)	Yield Strength Min (MPa)	Tensile Strength (MPa)	Elongation Min (%)
SA516 Gr.60	0.24	0.60-0.90	0.15-0.30	0.035	0.035	220	415-550	25
SA516 Gr.70	0.28	0.85-1.20	0.15-0.30	0.035	0.035	260	485-620	21
SA537 Cl.1	0.24	0.70-1.35	0.15-0.50	0.035	0.035	290	485-620	22
SA537 Cl.2	0.24	0.70-1.35	0.15-0.50	0.035	0.035	310	515-655	22
P265GH	0.20	0.80-1.40	≤0.40	0.025	0.030	265	410-530	24
P355GH	0.20	1.00-1.60	≤0.50	0.025	0.030	355	490-630	22
P355NH	0.20	1.00-1.60	≤0.50	0.025	0.030	355	490-630	22
P355NL	0.18	1.00-1.60	≤0.50	0.020	0.025	355	490-630	22

Detailed Technical Specifications

Item	Specification
Product Name	SA516 Gr.60 / Gr.70, SA537 Cl.1 / Cl.2, P265GH, P355GH, P355NH / NL Pressure Vessel Steel Plate
Standard	ASME SA516, ASME SA537, EN 10028-3, EN 10028-4
Thickness	6mm – 200mm
Width	1000mm – 3000mm
Length	2000mm – 12000mm, custom cut available
Surface	Mill finish, shot blasting, painting
Test	MTC, UT, Charpy impact, chemical analysis
MOQ	5 Ton
Trade Terms	FOB, CFR, CIF, EXW, DDP
Payment Term	T/T, L/C at sight
Delivery Time	7 – 25 working days
Packing	Standard seaworthy packing, wooden pallet or bulk loading
Application	Pressure vessels, chemical equipment, industrial storage tanks

Product Comparison Table

Grade	Standard	Minimum Yield Strength	Tensile Range	Main Feature	Typical Application
SA516 Gr.60	ASME SA516	220MPa	415-550MPa	General purpose carbon vessel plate	Normal temperature storage tank, low-pressure vessel
SA516 Gr.70	ASME SA516	260MPa	485-620MPa	Higher strength, most popular ASME grade	Welded pressure vessel, heat exchanger
SA537 Cl.1	ASME SA537	290MPa	485-620MPa	Normalized C-Mn steel, good toughness	Thick wall pressure vessel
SA537 Cl.2	ASME SA537	310MPa	515-655MPa	Higher strength version of SA537	Heavy duty pressure equipment
P265GH	EN10028-3	265MPa	410-530MPa	Low strength EN boiler/vessel steel	European standard small pressure vessel
P355GH	EN10028-3	355MPa	490-630MPa	Normalized high strength EN grade	Medium pressure vessel, boiler component
P355NH	EN10028-3	355MPa	490-630MPa	Normalized, room/low temp service	Chemical vessel, power equipment
P355NL	EN10028-4	355MPa	490-630MPa	Fine grain, low temperature toughness	Low temperature pressure tank

App Market

Reliable Steel Coil Solutions For Diverse Industrial Applications

Boiler Drum

Water Wall

Superheater

Heat Exchangers

Power Plant Headers

Gas Storage Tanks

Chemical Reactors

LNG Storage Tanks

Pipeline Heads

Separators

Product Packaging

Secure Export Packaging For Safe Handling And Delivery

FAQs

What is the difference between SA516 Gr70 and P355GH?

SA516 Gr70 follows ASME standard widely used in American & Middle East projects; P355GH complies with EN European standard. They have similar tensile range, but different chemical composition and impact test requirements.

Can you provide UT ultrasonic test for these pressure vessel steel plates?

Yes, 100% ultrasonic inspection is available as customer requirement, the UT report will be supplied with MTC.

What is MOQ for this pressure vessel steel plate?

Our MOQ is 5 ton.

Can you cut the steel plate to custom size?

Yes, flame cutting, plasma cutting and machining service are available, we can process plates according to your drawing.

What certificates can you provide?

We can provide Mill Test Certificate (MTC), SGS, BV, ISO inspection documents. Third-party inspection is acceptable before shipment.
