Weathering Corten Steel Plate Supplier

Weathering Corten Steel Plate

Self-forming rust patina layer blocks air & moisture, greatly lowering later anti-corrosion maintenance cost.
Multi-standard grade system matches outdoor environment of Europe, America, Japan and domestic projects.
Complete size range, supply both steel plate and steel coil with custom cutting service available.
Good plasticity & welding performance, easy to process into sculptures, containers and bridge components.
Long service life under natural atmospheric corrosion, stable physical properties for long-term outdoor exposure.

Product Overview

Weathering Corten steel plate is an atmospheric corrosion-resistant structural steel designed for long-term outdoor service environments. Manufactured according to ASTM A242, GB/T4171, EN 10025, and JIS weathering steel standards, it provides durable performance for architectural, transportation, and industrial outdoor projects.

The product covers multiple global grade systems, including Corten A, Corten B, ASTM A588 Gr.A/B/C/K, ASTM A242, ASTM A709 Gr.50W, S355J0WP, S355J2W, S355K2W, SPA-H, SPA-C, Q235NH, Q345NH, Q355NH, and Q355GNH, meeting different regional engineering requirements.

Unlike ordinary steel, Corten weathering steel forms a dense and stable protective rust patina layer naturally when exposed to outdoor atmospheric conditions. This protective layer reduces the need for regular painting and anti-corrosion maintenance while maintaining good welding, cutting, bending, and forming performance.

With thicknesses from 1.5–100mm, multiple width and length options, steel plate and coil supply, and customized cutting services, the product is widely used in outdoor sculptures, building curtain walls, landscape structures, shipping containers, railway vehicles, bridge structures, and power plant chimneys.

Weathering Corten Steel Plate (Corten A/B)

Chemical & Mechanical Property Snapshot

Grade	Standard	C Max (%)	Mn (%)	Si (%)	P Max (%)	S Max (%)	YS Min (MPa)	TS (MPa)	El Min (%)	Key Alloy Elements
Corten A (A242)	ASTM A242	0.12	0.20–0.50	0.25–0.75	0.15	0.05	345	480–620	22	Cu 0.25–0.55, Cr 0.40–1.25
Corten B (A588 Gr.A)	ASTM A588	0.19	0.80–1.25	0.30–0.65	0.04	0.05	345	485–620	21	Cu 0.25–0.40, Cr 0.40–0.65, Ni 0.25–0.40
A588 Gr.B	ASTM A588	0.20	0.75–1.35	0.15–0.50	0.04	0.05	345	485–620	21	Cu 0.20–0.40
A588 Gr.C	ASTM A588	0.15	0.80–1.30	0.15–0.50	0.04	0.05	345	485–620	21	Cu 0.20–0.40, Ni ≤0.25
A588 Gr.K	ASTM A588	0.17	0.50–1.20	0.15–0.40	0.04	0.05	345	485–620	21	Cu 0.20–0.40, Ni 0.25–0.50, Cr 0.40–0.70
A709 Gr.50W	ASTM A709	0.15	0.80–1.25	0.30–0.65	0.02	0.006	345	485–620	21	Cu 0.25–0.40, Ni 0.15–0.30, Cr 0.40–0.70
S355J0WP	EN 10025-5	0.12	≤1.00	≤0.75	0.15	0.03	355	470–630	22	Cr 0.30–1.00, Cu 0.25–0.55
S355J2WP	EN 10025-5	0.13	0.50–1.50	≤0.50	0.035	0.035	355	470–630	22	Cr 0.40–0.80, Cu 0.25–0.55, Ni ≤0.65
S355K2W	EN 10025-5	0.13	0.50–1.50	≤0.50	0.035	0.03	355	470–630	22	Cr 0.40–0.80, Cu 0.25–0.55, Ni ≤0.65
SPA-H	JIS G3125	0.12	≤0.60	0.25–0.75	0.15	0.04	245	≥480	22	Cu 0.25–0.50, Cr 0.20–0.30
SPA-C	JIS G3125	0.12	≤0.60	0.15–0.50	0.15	0.04	265	≥490	19	Cu 0.20–0.50, Cr 0.20–0.30
Q235NH	GB/T 4171	0.15	0.20–0.60	0.15–0.40	0.035	0.035	235	360–490	25	Cu ≥0.20, Cr ≤0.80
Q355NH	GB/T 4171	0.16	0.90–1.50	≤0.50	0.03	0.025	355	470–630	22	Cu 0.20–0.50, Cr 0.40–0.80, Ni ≤0.65
Q355GNH	GB/T 4171	0.12	0.20–0.60	0.20–0.60	0.12	0.02	355	≥480	22	Cu 0.25–0.55, Cr 0.30–1.25

Detailed Technical Specifications

Category	Item
Product Name	Weathering Corten Steel Plate
Product Type	Atmospheric Corrosion Resistant Structural Steel Plate
Applicable Standards	ASTM A242, GB/T4171, EN 10025, JIS Weathering Steel Standards
Corten Series	Corten A, Corten B
American Standard Grades	ASTM A588 Gr.A/B/C/K, ASTM A242, ASTM A709 Gr.50W
European Standard Grades	S355J0WP, S355J2W, S355K2W
Japanese Standard Grades	SPA-H, SPA-C
Domestic Standard Grades	Q235NH, Q345NH, Q355NH, Q355GNH
Thickness Range	1.5–100mm
Width Range	1000mm, 1250mm, 1500mm, 2000mm, 2500mm
Length Range	2000–12000mm
Supply Form	Steel Plate and Steel Coil
Surface Performance	Forms a dense and stable protective rust patina layer under natural atmospheric exposure
Processing Capability	Cutting, bending, welding, carving, and customized processing
Performance Features	Atmospheric corrosion resistance, stable physical properties, good plasticity and weldability
Main Applications	Outdoor sculptures, curtain walls, landscape flower beds, shipping containers, railway vehicles, bridge structures, power plant chimneys
MOQ	5 Ton
Trade Terms	FOB, CFR, CIF, DDP, EXW
Payment Terms	T/T, L/C at Sight, Western Union, Trade Assurance
Delivery Time	3-7 days for in-stock goods; 10-25 days for customized production
Packaging Standard	Standard seaworthy export packing, wooden pallets / steel bundles, waterproof and rust-proof film, fixed with steel strips

Product Comparison Table

Grade System	Typical Grades	Main Characteristics	Recommended Applications
Corten / ASTM Weathering Steel	Corten A, Corten B, ASTM A242, A588 Gr.A/B/C/K, A709 Gr.50W	Classic weathering steel grades with strong atmospheric corrosion resistance, forming a stable rust patina without frequent painting	Bridges, outdoor structures, architectural art projects
European Weathering Steel	S355J0WP, S355J2WP, S355K2W	EN standard weathering steel; S355J0WP high phosphorus version for thin plates; S355J2W/S355K2W low phosphorus grades for heavy structures	Building structures and landscape engineering
Japanese Weathering Steel	SPA-H, SPA-C	High phosphorus weathering steel with good patina-forming performance	Shipping containers and transportation equipment
Domestic Weathering Steel	Q235NH, Q355NH, Q355GNH (Q345NH: old standard grade, available upon request)	Weather-resistant steel grades designed for local engineering requirements	Construction and outdoor facilities
Weathering Steel Coil	Weathering steel coil	Flexible raw material form suitable for deep processing	Customized fabrication and industrial manufacturing

App Market

Reliable Steel Coil Solutions For Diverse Industrial Applications

Outdoor Sculpture

Curtain Wall & Planter

Shipping Container

Railway Wagon

Bridge Structure

Power Plant Chimney

Product Packaging

Secure Export Packaging For Safe Handling And Delivery

FAQs

What is weathering Corten steel plate?

Weathering Corten steel plate is an atmospheric corrosion-resistant steel that forms a protective rust patina layer naturally during outdoor exposure.

What standards are available for Corten weathering steel plate?

Available standards include ASTM A242, GB/T4171, EN 10025, and JIS weathering steel specifications.

What grades are available for weathering steel plate?

The product includes Corten A/B, ASTM A588, ASTM A242, A709 Gr.50W, S355J0WP, SPA-H, SPA-C, and NH series grades.

Can weathering Corten steel plate be processed?

Yes. The material supports cutting, bending, welding, carving, and customized processing operations.

Where is weathering steel plate used?

It is widely used in outdoor sculptures, curtain walls, landscape structures, containers, railway vehicles, bridges, and power plant chimneys.
