Corten A Corten B ASTM A242 A588 Gr.A/B/C/K A709 Gr.50W Weathering Steel Plate

Natural rust patina layer blocks moisture & air, cuts long-term anti-corrosion maintenance cost
ASTM certified weathering steel, stable performance for long-time outdoor exposure
Excellent weldability and formability, easy to fabricate for architectural & bridge projects
Wide size selection, custom cutting service available to match your drawing requirements
Reliable quality with MTC 3.1/3.2 certificate, full inspection before shipment

Product Overview

Corten A / Corten B / ASTM A242 / A588 Gr.A/B/C/K / A709 Gr.50W Weathering Steel Plate is ASTM standard atmospheric corrosion resistant structural steel, widely known as Corten steel. Manufactured strictly following ASTM A242, ASTM A588 and ASTM A709 standards, this series steel contains Cu, Cr, Ni alloy elements. When exposed to outdoor atmospheric environment, it will automatically form a dense, stable rust patina layer on the surface, which prevents further corrosion of the steel substrate without frequent paint coating.

This ASTM weathering steel series covers Corten A, Corten B, A242, A588 Gr.A/B/C/K and A709 Gr.50W grades. It features high strength, good plasticity, outstanding welding and bending performance. The thickness range is 1.5–100mm, customizable width and length available, we can provide steel plate and steel coil with cutting service.

It is the preferred material for bridges, outdoor sculpture, landscape structures, building facade, railway vehicle and other long-service outdoor engineering projects. All products come with mill test certificate to guarantee chemical and mechanical properties.

Weathering Corten Steel Plate (Corten A/B)

Chemical & Mechanical Property Snapshot

Grade	Standard	C Max (%)	Mn (%)	Si (%)	P Max (%)	S Max (%)	YS Min (MPa)	TS (MPa)	El Min (%)	Key Alloy Elements
Corten A (A242)	ASTM A242	0.12	0.20–0.50	0.25–0.75	0.15	0.05	345	480–620	22	Cu 0.25–0.55, Cr 0.40–1.25
Corten B (A588 Gr.A)	ASTM A588	0.19	0.80–1.25	0.30–0.65	0.04	0.05	345	485–620	21	Cu 0.25–0.40, Cr 0.40–0.65, Ni 0.25–0.40
A588 Gr.B	ASTM A588	0.20	0.75–1.35	0.15–0.50	0.04	0.05	345	485–620	21	Cu 0.20–0.40
A588 Gr.C	ASTM A588	0.15	0.80–1.30	0.15–0.50	0.04	0.05	345	485–620	21	Cu 0.20–0.40, Ni ≤0.25
A588 Gr.K	ASTM A588	0.17	0.50–1.20	0.15–0.40	0.04	0.05	345	485–620	21	Cu 0.20–0.40, Ni 0.25–0.50, Cr 0.40–0.70
A709 Gr.50W	ASTM A709	0.15	0.80–1.25	0.30–0.65	0.02	0.006	345	485–620	21	Cu 0.25–0.40, Ni 0.15–0.30, Cr 0.40–0.70

Detailed Technical Specifications

Category	Item
Product Name	Corten A / Corten B / ASTM A242 / A588 Gr.A/B/C/K / A709 Gr.50W Weathering Steel Plate
Product Type	ASTM Standard Atmospheric Corrosion Resistant Structural Steel Plate
Applicable Standards	ASTM A242, ASTM A588, ASTM A709
Grades	Corten A, Corten B, ASTM A242, A588 Gr.A/B/C/K, A709 Gr.50W
Thickness Range	1.5–100mm
Width Range	1000mm, 1250mm, 1500mm, 2000mm, 2500mm
Length Range	2000–12000mm
Supply Form	Steel Plate and Steel Coil
Surface Performance	Forms dense stable protective rust patina under natural atmospheric exposure
Processing Capability	Cutting, bending, welding, carving, custom fabrication per drawings
Performance Features	Excellent atmospheric corrosion resistance, stable physical properties, good plasticity and weldability
Main Applications	Bridges, outdoor structures, architectural art, landscape sculpture, railway components
MOQ	5 Ton
Trade Terms	FOB, CFR, CIF, DDP, EXW
Payment Terms	T/T, L/C at Sight, Western Union, Trade Assurance
Delivery Time	3–7 days for in-stock goods; 10–25 days for customized production
Packaging Standard	Standard seaworthy export packing, wooden pallets / steel bundles, waterproof and rust-proof film, fixed with steel strips
Certificate	MTC 3.1 / 3.2, ISO, SGS, BV

Product Comparison Table

Grade System	Typical Grades	Main Characteristics	Recommended Applications
Corten / ASTM Weathering Steel	Corten A, Corten B, ASTM A242, A588 Gr.A/B/C/K, A709 Gr.50W	Classic ASTM weathering steel, strong atmospheric corrosion resistance, naturally form stable rust patina, low later maintenance	Bridges, outdoor structures, architectural sculpture, landscape art projects

App Market

Reliable Steel Coil Solutions For Diverse Industrial Applications

Outdoor Sculpture

Curtain Wall & Planter

Shipping Container

Railway Wagon

Bridge Structure

Power Plant Chimney

Product Packaging

Secure Export Packaging For Safe Handling And Delivery

FAQs

What is the difference between Corten A and Corten B?

Corten A is equivalent to ASTM A242, higher phosphorus content, mainly for thin plates; Corten B equals A588 Gr.A, lower phosphorus, more suitable for thick heavy structural components.

Do you provide MTC certificate for ASTM weathering steel plate?

Yes, we supply EN10204 3.1 or 3.2 mill test certificate for each batch, to verify chemical and mechanical properties.

Can you cut Corten steel plate according to customer drawings?

Custom cutting service available. We can cut plates into required size, bending and welding processing also supported.

How long will Corten steel form the rust patina layer?

Under normal outdoor wet-dry cycling environment, stable protective rust patina will form within 6–18 months.

What is your MOQ and delivery time?

MOQ is 5 tons. Stock goods delivery in 3-7 days, customized production takes 10-25 days.
