321 Stainless Steel Coil | 06Cr18Ni11Ti Titanium Stabilized Stainless Steel Coil

Titanium stabilized alloy, prevent intergranular corrosion under high temperature condition
Stable mechanical property under continuous high-temperature working environment
Good welding performance without post weld heat treatment
Great creep resistance at elevated temperature
Wide application for boiler, exhaust pipe and high-temperature equipment

Product Overview

321 stainless steel coil GB grade 06Cr18Ni11Ti, equivalent to AISI321, SUS321 and EN 1.4541 (X6CrNiTi18-10). Titanium element is added to fix carbon, avoid chromium carbide precipitation under high temperature. It keeps outstanding anti-corrosion performance after long time high temperature service.

We can supply cold rolled and hot rolled 321 stainless steel coil, surface No.1, 2B. Custom slitting service to narrow stainless steel strip is available. Typical usage: high temperature pipeline, boiler component, heat exchanger, engine exhaust manifold, furnace auxiliary equipment.

Stainless Steel Coil

Chemical & Mechanical Property Snapshot

Category	Element / Index	Standard Requirement
Chemical Composition (wt%)	Carbon (C)	≤0.08
	Silicon (Si)	≤1.00
	Manganese (Mn)	≤2.00
	Phosphorus (P)	≤0.045
	Sulfur (S)	≤0.030
	Chromium (Cr)	17.00 ~ 19.00
	Nickel (Ni)	9.00 ~ 12.00
	Titanium (Ti)	≥5×C
Mechanical Properties	Yield Strength Rp0.2	≥205 MPa
	Tensile Strength Rm	≥515 MPa
	Elongation A	≥40 %
	Hardness HV	≤200 HV

Detailed Technical Specifications

Specification Item	Parameter Details
Grade	321 / 06Cr18Ni11Ti
Executive Standard	GB/T 20878, ASTM A240, JIS G4305, EN 10088-2
Rolling Type	Cold Rolled / Hot Rolled
Thickness Range	Cold Rolled:0.3mm–3.0mm; Hot Rolled:3.0mm–14mm
Thickness Tolerance	CR: ±0.02~0.05mm; HR: ±0.1~0.3mm, custom tolerance acceptable
Width Range	100mm–1500mm, custom slitting service available
Width Tolerance	±0.5mm ~ ±2mm based on width
Inner Diameter	508mm / 610mm
Surface Finish	2B, No.1
Coil Weight	1–25 Tons per coil
Delivery Condition	Annealed & Pickled / Bright Annealed
Edge Type	Slit Edge / Mill Edge
Certificate	MTC, EN 10204 3.1, third-party inspection SGS/BV available
Packing	Waterproof paper + metal protective cover, seaworthy export packing
MOQ	5 Ton for standard stock sizes
Lead Time	Stock items:7–15 days; Custom non-standard:20–35 days

Product Comparison Table

Grade	GB Standard	AISI (US)	SUS (JIS)	EN Standard (Material No. & Full Designation)	Brief Application
201	1Cr17Mn6Ni5N	201	SUS201	1.4372, X12CrMnNi17-7-5	Low-nickel austenitic stainless steel, economical material, indoor decoration, kitchenware
202	–	202	SUS202	1.4373, X12CrMnNi18-9-5	Manganese-nickel stainless steel, indoor decorative panels, low-corrosion environment parts
301	1Cr17Ni7	301	SUS301	1.4310, X10CrNi18-8	High work hardening rate, elastic strips, springs, stamping components
303	Y06Cr19Ni10	303	SUS303	1.4305, X8CrNiS18-9	Free-cutting stainless steel, automatic lathe parts, bolts & precision fasteners
304	06Cr19Ni10	304	SUS304	1.4301, X5CrNi18-10	General-purpose austenitic stainless steel, construction, kitchenware, general industrial equipment
304L	022Cr19Ni10	304L	SUS304L	1.4307, X2CrNi18-9	Low carbon 304, prevent intergranular corrosion after welding, welded vessels & pipes
304N	022Cr19Ni10N	304N	SUS304N1	1.4311, X2CrNiN18-10	Nitrogen strengthened grade, higher tensile strength, thin wall structural parts
316	06Cr17Ni12Mo2	316	SUS316	1.4401, X5CrNiMo17-12-2	Molybdenum added, chloride corrosion resistant, chemical & seawater auxiliary equipment
316L	022Cr17Ni12Mo2	316L	SUS316L	1.4404, X2CrNiMo17-12-3	Low carbon 316, excellent weldability, chemical tanks, marine piping
317L	022Cr19Ni13Mo4	317L	SUS317L	1.4438, X2CrNiMo18-15-4	Higher Mo content, resist reducing acid & pitting corrosion, pulp & chemical industry
321	06Cr18Ni11Ti	321	SUS321	1.4541, X6CrNiTi18-10	Titanium stabilized, anti high-temp intergranular corrosion, high-temperature pipelines
309S	06Cr23Ni13	309S	SUS309S	1.4828, X15CrNiSi20-12	High-temperature oxidation resistance, furnace linings, heat treatment equipment
310S	06Cr25Ni20	310S	SUS310S	1.4845, X12CrNi25-21	Ultra-high temperature resistant, kilns, high-temperature furnace components
430	06Cr17	430	SUS430	1.4016, X6Cr17	Ferritic stainless steel, good formability, home appliances, decorative trims
409L	022Cr11Ti	409L	SUS409L	1.4512, X2CrTi12	Titanium stabilized ferritic steel, automotive exhaust system
410S	06Cr13	410S	SUS410S	1.4000, X6Cr13	Low carbon martensitic stainless steel, moderate corrosion resistance, general anti-rust parts
410	12Cr13	410	SUS410	1.4006, X12Cr13	Heat-treatable martensitic steel, pumps, valves, mechanical wear parts
420	20Cr13	420	SUS420	1.4021, X20Cr13	Hardenable martensitic grade, blades, cutlery, wear resistant machinery parts
420J2	30Cr13	420J2	SUS420J2	1.4031, X30Cr13	High carbon martensitic stainless, superior polishing performance, precision hardware
2205 Duplex	022Cr22Ni5Mo3N	2205	–	1.4462, X2CrNiMoN22-5-3	Duplex stainless steel, high strength, excellent pitting resistance, oil & gas equipment
2507 Super Duplex	022Cr25Ni7Mo4N	2507	–	1.4410, X2CrNiMoN25-7-4	Super duplex steel, strong chloride corrosion resistance, offshore platform equipment
904L	022Cr25Ni7Mo4CuN	904L	–	1.4539, X1NiCrMoCu25-20-5	Super austenitic stainless steel, resistant to strong acid, phosphoric acid industry
630	05Cr17Ni4Cu4Nb	630	SUS630	1.4542, X5CrNiCuNb17-4-4	Precipitation hardening stainless steel, high strength, aerospace & mechanical components

App Market

Reliable Steel Coil Solutions For Diverse Industrial Applications

Curtain Wall & Planter

Kitchen & Bathroom Appliances Stainless Steel

Food Can Body ETP

Pressure Vessels Stainless Steel

Boiler Drum

Petrochemical Equipment-Stainless Steel

Product Packaging

Secure Export Packaging For Safe Handling And Delivery

FAQs

What is equivalent grade of 321 stainless steel coil?

GB 06Cr18Ni11Ti, AISI 321, SUS321, EN 1.4541 (X6CrNiTi18-10).

What is the main feature of 321 stainless coil?

Titanium stabilized, designed for high temperature working environment, avoid intergranular corrosion after heating and welding.

What are typical applications?

High temperature pipe, boiler, heat exchanger, engine exhaust manifold, furnace accessories.

What is the difference between 321 and 304?

321 added titanium, better anti-corrosion performance under high temperature, 304 for normal temperature environment.

Can you slit 321 coil to narrow strip?

Yes, custom slitting service available for stainless steel strip.

What documents can you offer?

EN10204 3.1 MTC certificate, third-party inspection can be arranged.
