13CrMo44 10CrMo910 EN10216‑2 High Pressure Alloy Steel Pipe

13CrMo44 10CrMo910 EN10216‑2 High Pressure Alloy Steel Pipe | EN Heat Resistant Alloy Pipe

Fully compliant with EN10216‑2 European pressure‑bearing pipe standard
Reliable high‑temperature creep resistance for long‑term equipment service life
Strict dedicated heat‑treatment process, stable and repeatable mechanical performance
Multiple shape options: round, square, rectangular & custom special shapes
Full material heat‑number traceability, suitable for EU industrial pressure‑equipment projects

Product Overview

13CrMo44 and 10CrMo910 are European‑standard seamless alloy steel pipes manufactured to EN10216‑2 for pressure purposes. 13CrMo44 belongs to 1Cr‑0.5Mo alloy grade, equivalent to ASTM A213 T12; 10CrMo910 is 2Cr‑1Mo alloy material designed for higher‑temperature working environment. These alloy pipes are widely used in European boiler system, power plant, chemical high‑temperature pipeline and heat‑exchange equipment. We provide seamless hot‑rolled and cold‑drawn pipes, including standard round pipe, square, rectangular alloy tube and custom special‑shaped pipes made according to client drawings.

High Pressure Alloy Steel Pipe

Chemical & Mechanical Property Snapshot

Grade	C (%)	Si (%)	Mn (%)	Cr (%)	Mo (%)	Yield Strength (MPa)	Tensile Strength (MPa)	Elongation (%)
13CrMo44	0.10~0.18	0.15~0.35	0.40~0.70	0.70~1.10	0.40~0.50	≥290	440~590	≥22
10CrMo910	0.08~0.15	≤0.50	0.40~0.70	2.00~2.50	0.90~1.10	≥270	450~600	≥20

Detailed Technical Specifications

Item	Specification
Product Name	EN10216‑2 High‑pressure Heat‑resistant Alloy Seamless Steel Pipe
Material Grades	13CrMo44, 10CrMo910
Executive Standard	EN 10216‑2
Product Form	Seamless pipe: Round / Square / Rectangular / Custom special shape
Manufacturing Process	Hot‑rolled seamless / Cold‑drawn seamless
Heat Treatment	Normalizing + Tempering complying with EN requirement
Outer Diameter Range	21.3mm ‑ 355.6mm
Wall Thickness Range	2.0mm ‑ 45mm
Available Length	Random length: 4‑12m; Fixed custom length: 1‑12m
Surface Condition	Black hot‑rolled surface / Anti‑rust oil / Black painting
Pipe End Treatment	Plain end / Bevel end for welding; plastic end caps protection
Mandatory Inspection	Hydrostatic test, Ultrasonic test(UT), chemical analysis, tensile test, hardness test
Optional Inspection	MT, PT
Document & Certificate	Mill Test Certificate(MTC), inspection report, heat‑number traceability document
MOQ(Minimum Order Quantity)	5 Ton; mixed sizes acceptable upon negotiation
Trade Terms	FOB, CFR, CIF, EXW
Payment Terms	T/T, L/C at sight
Packaging Detail	Both ends fitted with waterproof plastic caps; wrapped with waterproof kraft paper; bundled by high‑strength steel strips; wooden crate / pallet for special‑shaped pipe optional
Lead Time	18‑28 working days against deposit
Additional Available Service	Saw cutting, fixed‑length cutting, surface blasting, marking printing, custom‑shape fabrication per drawing

Shape Options

Available Pipe Shapes
Round High‑Pressure Alloy Pipe: Main product for boiler, heat‑exchanger, high‑pressure process pipeline, full Sch40‑Sch160 heavy wall sizes
Square Alloy Steel Pipe: Custom seamless square alloy tube for high‑pressure structural frame, pressure equipment support
Rectangular Alloy Steel Pipe: Custom seamless rectangular alloy profile for heavy‑duty industrial structural components
Special‑Shaped Alloy Pipe: Oval, hexagon and other special cross‑section, non‑standard dimension upon customer drawing

Dimension Reference Table

Outer Diameter	OD (inch)	Wall Thickness	WT (inch)
21.3 mm	0.84″	2.0 ~ 4.0 mm	0.079″ ~ 0.157″
33.7 mm	1.33″	2.5 ~ 6.0 mm	0.098″ ~ 0.236″
42.4 mm	1.67″	3.0 ~ 8.0 mm	0.118″ ~ 0.315″
48.3 mm	1.90″	3.0 ~ 10 mm	0.118″ ~ 0.394″
60.3 mm	2.37″	3.5 ~ 12 mm	0.138″ ~ 0.472″
88.9 mm	3.50″	4.0 ~ 16 mm	0.157″ ~ 0.630″
114.3 mm	4.50″	4.5 ~ 20 mm	0.177″ ~ 0.787″
168.3 mm	6.63″	6.0 ~ 25 mm	0.236″ ~ 0.984″

Product Comparison Table

Grade	Standard	Equivalent Grade	Main Application
13CrMo44	EN10216‑2	15CrMoG, A213 T12	Boiler, high temperature pipeline
10CrMo910	EN10216‑2	12Cr1MoVG, A213 T11	Power plant reheater, chemical process pipe

App Market

Reliable Steel Coil Solutions For Diverse Industrial Applications

Coal Chemical Syngas Pipeline

High-Pressure Piping for Hydrocracking Units

Main Steam Pipeline of Thermal Power Plant Boilers

Product Packaging

Secure Export Packaging For Safe Handling And Delivery

FAQs

What is EN10216‑2 standard used for?

EN10216‑2 is European standard for seamless steel tubes for pressure purposes, alloy steel for elevated‑temperature service.

Can EN10216‑2 alloy pipe match ASTM grades?

Yes, 13CrMo44 equivalent to A213 T12; 10CrMo910 equivalent to A213 T11.

MOQ for EN alloy pipe?

MOQ 5 tons, mixed sizes acceptable.

Can we get custom length?

Yes, cut‑to‑length service available.

Can you manufacture special shaped alloy pipe?

Yes, square, rectangular and custom profiles are available with engineering drawings.
