310S Stainless Steel Hexagonal Bar | SUS310S Hex Bar ASTM A276 GB/T4228

Outstanding high temperature oxidation resistance up to 1150℃ continuous service
Excellent thermal strength for furnace, boiler and heat treatment equipment
Stable performance under cyclic heating & cooling working conditions
Low creep rate under long-time high temperature load
Compliant with GB/T4228, ASTM A276, EN10088 for high-temperature industrial projects

Product Overview

310S Stainless Steel Hexagonal Bar (SUS310S, 1.4845 / X12CrNi25-21 / 06Cr25Ni20) is high nickel-chromium austenitic stainless steel hexagonal solid bar for high temperature service, produced to GB/T4228, ASTM A276 and EN10088 specifications. High Cr & Ni content delivers superb oxidation resistance at extreme high temperature.

The near-net hexagonal shape reduces secondary cutting work for high-temperature hex bolts and furnace connectors. Our 310S hex bar covers across-flat dimension S6mm to S80mm, mainstream sizes S8, S10, S12, S14, S17, S19, S22, S24, S27, S30, S32, S36, S41, S46, S50.

Main applications: furnace internal fasteners, boiler components, heat treatment fixtures, kiln equipment parts, high-temperature pipeline connectors. Every batch can supply MTC to verify chemical composition and high-temperature mechanical performance.

Stainless Steel Hexagonal Bar

Chemical & Mechanical Property Snapshot

Grade	Equivalent Grade	C Max	Cr	Ni	Mo	Mn	Yield Strength (MPa) Min	Tensile Strength (MPa) Min	Elongation (%) Min	Hardness HB Max
310S	1.4845 / X12CrNi25-21 / SUS310S / 06Cr25Ni20	0.08	24.00-26.00	19.00-22.00	—	2.00	205	515	40	217

Detailed Technical Specifications

Item	Specification
Product Name	310S Stainless Steel Hexagonal Bar
Material Type	310S High Temperature Austenitic Stainless Steel
Shape	Solid Hexagonal Cross Section
Production Standards	GB/T4228, ASTM A276, EN10088
Across Flats Dimension	S6mm – S80mm
Mainstream Sizes	S8, S10, S12, S14, S17, S19, S22, S24, S27, S30, S32, S36, S41, S46, S50
Material Performance	High temperature oxidation resistance, stable thermal strength
Typical Processing	Furnace fasteners, boiler fittings, kiln & heat treatment components
Quality Control	Mill Test Certificate including heat number, chemical composition and mechanical property data
Export Packing	Bundled seaworthy packing to prevent bruising and scratching
MOQ	5 Ton
Payment Terms	T/T, L/C at Sight
Delivery Time	7–15 working days after receiving deposit

Dimension Table

Across Flats Size (S)	Weight (kg/m)	Tolerance
S6	0.247	±0.08 mm
S8	0.442	±0.08 mm
S10	0.690	±0.10 mm
S12	0.991	±0.10 mm
S14	1.344	±0.12 mm
S17	1.980	±0.12 mm
S19	2.460	±0.15 mm
S22	3.280	±0.15 mm
S24	3.910	±0.15 mm
S27	4.930	±0.20 mm
S30	6.080	±0.20 mm
S32	6.990	±0.20 mm
S36	8.830	±0.25 mm
S41	11.45	±0.25 mm
S46	14.40	±0.30 mm
S50	16.98	±0.30 mm
S60	24.45	±0.35 mm
S70	33.35	±0.40 mm
S80	43.67	±0.40 mm

Product Comparison Table

Comparison Item	310S Stainless Steel Hexagonal Bar	310S Stainless Steel Round Bar	310S Stainless Steel Square Bar
Cross Section	Hexagonal	Round	Square
Main Purpose	High temperature hex bolts, furnace threaded fasteners	High temp shafts, heat treatment rollers	High temp support frames, furnace fixtures
Machining Advantage	Near-net hex profile reduces cutting work, saves raw material and processing time	Requires secondary machining for hex shapes, more material waste	Stable square geometry, good for welding high temp assemblies
Standards	GB/T4228, ASTM A276, EN10088	GB/T1220, ASTM A276, EN10088	GB/T1220, ASTM A276, EN10088
Application Fields	Kiln fasteners, boiler internal parts, heat treatment furnace hardware	High temperature rotating shafts, furnace transport rollers	Furnace support frames, heat treatment fixture bases
Key Buyer Value	Direct use for high-temperature hex fastener manufacturing, less machining	Flexible turning for custom high-temperature parts	Good structural stability under continuous high temperature
Corrosion Resistance	Good oxidation resistance at high temperature	Good oxidation resistance at high temperature	Good oxidation resistance at high temperature
Cost Level	High	Medium	High

App Market

Reliable Steel Coil Solutions For Diverse Industrial Applications

Seawater Valve Fasteners

Chemical Pipeline Threaded Fittings

Corrosion-Resistant Hex Bolts

Product Packaging

Secure Export Packaging For Safe Handling And Delivery

FAQs

What is the maximum working temperature of 310S hex bar?

Continuous service temperature up to 1150℃, suitable for high-temperature oxidation environment.

Can 310S be used in strong acid corrosion environment?

310S focuses on high-temperature oxidation resistance, not recommended for strong acid wet corrosion conditions.

What is equivalent grade for SUS310S hex bar?

Equivalent: 1.4845, X12CrNi25-21, 06Cr25Ni20.

Do you have stock for large size 310S hex bar?

Most common sizes available, large sizes may need production lead time.

Can you provide heat treatment service?

We can supply solution annealed 310S hex bar as customer requirement.
