904L Super Austenitic Stainless Steel Seamless Pipe, 1.4539 X1NiCrMoCu25-20-5 Tube

Superior resistance to sulfuric acid, phosphoric acid and other strong corrosive media
Low carbon content, excellent anti-intergranular corrosion performance
Good ductility and weldability for complex fabrication
Outstanding pitting and crevice corrosion resistance in chloride environment
Stable performance under wide temperature range for harsh chemical working conditions

Product Overview

Our 904L Super Austenitic Stainless Steel Seamless Pipe, also marked as 1.4539, X1NiCrMoCu25-20-5 and Chinese standard grade 022Cr25Ni20Mo4CuN, is a high-alloy low-carbon super austenitic stainless steel. It is produced by hot piercing and cold drawing process without welding seam, free of welding defects. With high nickel, molybdenum and copper content, this seamless pipe delivers powerful anti-corrosion capacity, especially suited for environments with dilute sulfuric acid, phosphoric acid and mixed acid. Widely used in chemical industry, fertilizer, marine engineering, flue gas desulfurization and paper making industries. Custom outer diameter, wall thickness and length are available, and full MTC material test certificates can be provided.

Stainless Steel Seamless Steel Pipe

Chemical & Mechanical Property Snapshot

Item	Value
Chemical Composition (wt%)
C	≤0.02
Si	≤1.00
Mn	≤2.00
P	≤0.040
S	≤0.030
Cr	19.00 – 23.00
Ni	23.00 – 28.00
Mo	4.00 – 5.00
Cu	1.00 – 2.00
Mechanical Property
Tensile Strength (Rm)	≥490 MPa
Yield Strength (Rp0.2)	≥215 MPa
Elongation (A)	≥35 %
Hardness (HB)	≤220

Detailed Technical Specifications

Specification Item	Details
Product Name	904L Super Austenitic Stainless Steel Seamless Pipe
Material Grade	904L / 1.4539 / X1NiCrMoCu25-20-5 / 022Cr25Ni20Mo4CuN
Production Process	Hot rolled / Cold drawn seamless
Outer Diameter	6mm – 630mm
Wall Thickness	1mm – 60mm
Length	Fixed length / Random length, custom available
Surface Finish	Pickled, polished
Standard	ASTM B677, EN 10216-5, GB/T 20878
Minimum Order Quantity	5 Tons
Production Lead Time	15-25 working days
Payment Term	T/T, L/C at sight
Certificate	MTC 3.1, EN 10204

Shape Section

Item	Shape Description	Notes
Primary Shape	Round / Circular Seamless Pipe	Most common form for stainless seamless pipe; stable OD & WT dimensional control; covers all grades (304, 304L, 316, 316L, 317L, 321, 309S, 310S, 2205, 2507, 904L)
Square Seamless Tube	Hollow square seamless profile	Cold-drawn seamless, no welding seam; suitable for structural and machinery applications
Rectangular Seamless Tube	Hollow rectangular seamless profile	Cold-drawn seamless, seamless construction; custom side dimensions available
Hexagonal Seamless Tube	Hexagonal hollow seamless bar / tube	Cold-drawn seamless; used for fittings and hydraulic parts
Octagonal Seamless Tube	Octagonal hollow seamless tube	Special custom cold-drawn seamless product; suitable for low-volume applications

Dimension Section

Item	Specification Details
Product Form	Stainless Steel Seamless Steel Pipe
Outer Diameter (OD) Range	6 mm–630 mm; Common stock OD: 10 mm, 12 mm, 16 mm, 20 mm, 25 mm, 32 mm, 38 mm, 42 mm, 48 mm, 57 mm, 60 mm, 76 mm, 89 mm, 102 mm, 114 mm, 168 mm, 219 mm, 273 mm, 325 mm
Wall Thickness (WT) Range	1.0 mm–40 mm; Common stock WT: 1.5 mm, 2.0 mm, 2.5 mm, 3.0 mm, 3.5 mm, 4.0 mm, 5.0 mm, 6.0 mm, 8.0 mm, 10 mm
Length	Fixed length: 3000 mm / 6000 mm / custom cut length; Random length: 4000–7000 mm
Tolerance	OD tolerance: ±0.1–±0.5 mm (depends on OD grade); Wall thickness tolerance: ±10%
End Type	Plain end / Beveled end
Surface Finish	Pickled / Bright annealed / Polished
Packaging	Wooden bundle / Wooden case

Product Comparison Table

AISI Grade	SUS Grade	EN Short Grade	EN Full Chemical Grade	GB Grade	Key Feature
304	SUS304	1.4301	X5CrNi18-10	06Cr19Ni10	General corrosion resistance, low strength
316L	SUS316L	1.4404	X2CrNiMo17-12-2	022Cr17Ni12Mo2	Better pitting resistance, austenitic
310S	SUS310S	1.4845	X12CrNi25-21	06Cr25Ni20	High temperature oxidation resistance
2205	–	1.4462	X2CrNiMoN22-5-3	022Cr22Ni5Mo3N	Duplex, high strength, excellent stress corrosion resistance
904L	–	1.4539	X1NiCrMoCu25-20-5	022Cr25Ni20Mo4CuN	Super austenitic, excellent resistance to strong acid

App Market

Reliable Steel Coil Solutions For Diverse Industrial Applications

Power Plant FGD Pipeline

Chemical Acid and Alkali Corrosive Media Transportation

Desalination Pipeline

Product Packaging

Secure Export Packaging For Safe Handling And Delivery

FAQs

What are equivalent grades of 904L stainless steel seamless pipe?

The equivalent grades of 904L are 1.4539, X1NiCrMoCu25-20-5 and Chinese standard 022Cr25Ni20Mo4CuN.

What is the main advantage of 904L compared with 316L?

904L contains higher nickel, molybdenum and copper. It can resist strong acid such as dilute sulfuric acid, which 316L cannot withstand.

Where is 904L seamless pipe commonly used?

It is widely applied in chemical processing, fertilizer plant, flue gas desulfurization, pulp & paper industry and seawater treatment.

Can you supply material test certificate?

Yes, MTC 3.1 certificate will be provided along with shipment.

What is your MOQ for 904L seamless pipe?

Minimum order quantity is 5 tons.
