EN39 S235GT Galvanized Scaffolding Pipe | Hot Dip Galvanized Carbon Steel Scaffolding Tube EN39 Certified

EN39 standard certified, meets EU construction heavy load requirements
Hot-dip galvanized surface, ≥200g/m² zinc coating for reliable corrosion resistance
Stable mechanical performance, suitable for ring-lock scaffolding systems
Available in multiple wall thickness options: 3.2mm,3.5mm,4.0mm
Custom service including length cutting, pipe end beveling & deburring

Product Overview

EN39 S235GT Galvanized Scaffolding Pipe is EN39 certified hot-dip galvanized carbon steel scaffolding tube, specially manufactured for European construction markets. Made of S235GT carbon steel substrate, the pipe adopts hot-dip galvanizing treatment with zinc coating weight ≥200g/m², offering 1-3 years outdoor service life. Its outer diameter is 48.3mm (1-1/2″ NPS, DN40), main wall thickness 3.2mm, optional 3.5mm and 4.0mm. It features high stable load capacity, widely used in European construction scaffolding, ring-lock systems and heavy-load building projects. We support length cutting, pipe end beveling and deburring customization, ideal for EU construction companies and overseas engineering contractors.

Galvanized Scaffolding Pipe

Chemical & Mechanical Property Snapshot

Item	Value
Grade	S235GT
Standard	BS EN 39
C (Carbon)	≤0.20%
Mn (Manganese)	≤1.40%
P (Phosphorus)	≤0.045%
S (Sulfur)	≤0.045%
Yield Strength	≥235 MPa
Tensile Strength	360–510 MPa
Elongation	≥25%

Detailed Technical Specifications

Item	Details
Product Name	EN39 S235GT Galvanized Scaffolding Pipe
Material Grade	S235GT
Standard	BS EN 39
Outer Diameter	48.3 mm (1-1/2″ NPS, DN40)
Wall Thickness	3.2 mm (main), 3.5 mm, 4.0 mm
Surface Treatment	Hot-dip galvanizing only
Zinc Coating Weight	≥200 g/m²
Customization Options	Length cutting, pipe end beveling & deburring
Minimum Order Quantity	5 Tons
Production Lead Time	15–25 working days after deposit
Payment Term	T/T, L/C at sight
Typical Application	European construction scaffolding, ring-lock systems, heavy-load projects

Dimension Section Table

Item	Specification
Outer Diameter	48.3 mm (1-1/2″ NPS, DN40)
Wall Thickness	3.0 mm
Wall Thickness	3.2 mm
Wall Thickness	3.5 mm
Wall Thickness	4.0 mm
Standard Length	6 m
Custom Cut Length	1 m
Custom Cut Length	2 m
Custom Cut Length	3 m
Custom Cut Length	4 m
Custom Cut Length	5 m
Custom Cut Length	6.4 m
Max Custom Length	12 m
Pipe End	Plain Cut / Optional Bevel & Deburring

Product Comparison Table

Comparison Item	EN39 S235GT Galvanized Scaffolding Pipe	Q235B Galvanized Scaffolding Pipe	BS1139 St44 Galvanized Scaffolding Pipe	S235JR Galvanized Scaffolding Pipe
Product Type	Hot-dip galvanized carbon steel scaffolding tube, EN39 certified	Hot-dip galvanized carbon steel scaffolding tube	Hot-dip galvanized carbon steel scaffolding tube, BS1139 certified	Hot-dip galvanized general structural steel scaffolding tube
Outer Diameter	48.3 mm (1-1/2″ NPS, DN40)	48.3 mm (1-1/2″ NPS, DN40)	48.3 mm (1-1/2″ NPS, DN40)	48.3 mm (1-1/2″ NPS, DN40)
Wall Thickness Options	3.2 mm (main), 3.5 mm, 4.0 mm	3.0 mm, 3.2 mm, 3.5 mm, 4.0 mm	3.0 mm, 3.2 mm, 3.5 mm, 4.0 mm	3.0 mm, 3.2 mm
Typical Application	European construction scaffolding, ring-lock systems, heavy-load projects	General building facade scaffolding, temporary support	UK construction scaffolding, building access platforms	Indoor temporary support, light-duty scaffolding
Load Capability	High stable load, meets EN39 construction requirements	Standard load-bearing capacity	Medium to heavy load capacity	Light & medium load scenarios
Surface Treatment	Hot-dip galvanizing only	Hot-dip galvanizing only	Hot-dip galvanizing only	Hot-dip galvanizing only
Zinc Coating Weight	≥200 g/m²	≥200 g/m²	≥200 g/m²	≥200 g/m²
Corrosion Resistance	1–3 years outdoor service life	1–3 years outdoor service life	1–3 years outdoor service life	1–2 years outdoor service life
Applicable Standards	BS EN 39, BS 1139	GB/T 13793, JGJ 130	BS 1139, GB/T 13793	EN 10025, GB/T 13793
Recommended Buyers	EU construction companies, overseas engineering contractors	Domestic & global building contractors, scaffolding rental companies	UK scaffolding importers, construction projects	General builders, temporary structure manufacturers
Customization Options	Length cutting, pipe end beveling & deburring	Length cutting, pipe end beveling & deburring	Length cutting, pipe end beveling & deburring	Length cutting

App Market

Reliable Steel Coil Solutions For Diverse Industrial Applications

Temporary Exhibition Stage Truss

Construction Working Platform

Coupler-Type Scaffolding for Building Exterior Wall Construction

Product Packaging

Secure Export Packaging For Safe Handling And Delivery

FAQs

What standard does EN39 S235GT galvanized scaffolding pipe comply with?

It is manufactured strictly according to BS EN 39 standard, also compatible with BS1139.

What is the zinc coating weight of EN39 S235GT scaffolding tube?

Zinc coating weight ≥200 g/m², hot-dip galvanized treatment for outdoor anti-corrosion.

What wall thickness options are available for S235GT scaffolding pipe?

Main thickness 3.2mm, optional 3.5mm and 4.0mm for heavy load projects.

Can we get custom cut length for EN39 scaffolding pipe?

Yes, we support length cutting, pipe end beveling and deburring service.

What is the MOQ and lead time?

MOQ is 5 tons. Lead time is 15–25 working days after receiving deposit.
