S235JR Galvanized Scaffolding Pipe, Hot-dip Galvanized General Structural Steel Scaffolding Tube

S235JR base material, excellent general structural performance
Hot-dip galvanized coating ≥200g/m² for reliable corrosion protection
Standard 48.3mm outer diameter, compatible with standard scaffolding couplers
Light & medium load capacity, ideal for indoor temporary support
Custom length cutting service available

Product Overview

S235JR Galvanized Scaffolding Pipe is hot-dip galvanized general structural steel scaffolding tube, manufactured conforming to EN 10025 and GB/T 13793 standards. This scaffolding tube adopts hot-dip galvanizing surface treatment with zinc coating weight ≥200g/m², offering 1–2 years outdoor service life. It comes with standard outer diameter of 48.3mm, wall thickness options of 3.0mm and 3.2mm. The pipe is designed for light & medium load scenarios, widely used for indoor temporary support and light-duty scaffolding projects. We provide length cutting service to meet different project requirements, popular among general builders and temporary structure manufacturers.

Galvanized Scaffolding Pipe

Chemical & Mechanical Property Snapshot

Item	Value
Grade	S235JR
Standard	EN 10025
C (Carbon)	≤0.17%
Mn (Manganese)	≤1.40%
Si (Silicon)	≤0.35%
P (Phosphorus)	≤0.045%
S (Sulfur)	≤0.045%
Yield Strength	≥235 MPa
Tensile Strength	360–510 MPa
Elongation	≥25%

Detailed Technical Specifications

Specification	Details
Product Name	S235JR Galvanized Scaffolding Pipe
Product Type	Hot-dip galvanized general structural steel scaffolding tube
Outer Diameter	48.3 mm (1-1/2″ NPS, DN40)
Wall Thickness Options	3.0 mm, 3.2 mm
Surface Treatment	Hot-dip galvanizing only
Zinc Coating Weight	≥200 g/m²
Applicable Standards	EN 10025, GB/T 13793
Typical Application	Indoor temporary support, light-duty scaffolding
Load Capability	Light & medium load scenarios
Corrosion Resistance	1–2 years outdoor service life
Customization Options	Length cutting
MOQ	5 Metric Tons
Lead Time	7–15 working days after deposit
Recommended Buyers	General builders, temporary structure manufacturers

Dimension Section Table

Item	Specification
Outer Diameter	48.3 mm (1-1/2″ NPS, DN40)
Wall Thickness	3.0 mm
Wall Thickness	3.2 mm
Wall Thickness	3.5 mm
Wall Thickness	4.0 mm
Standard Length	6 m
Custom Cut Length	1 m
Custom Cut Length	2 m
Custom Cut Length	3 m
Custom Cut Length	4 m
Custom Cut Length	5 m
Custom Cut Length	6.4 m
Max Custom Length	12 m
Pipe End	Plain Cut / Optional Bevel & Deburring

Product Comparison Table

Comparison Item	Q235B Galvanized Scaffolding Pipe	EN39 S235GT Galvanized Scaffolding Pipe	BS1139 St44 Galvanized Scaffolding Pipe	S235JR Galvanized Scaffolding Pipe
Product Type	Hot-dip galvanized carbon steel scaffolding tube	Hot-dip galvanized carbon steel scaffolding tube, EN39 certified	Hot-dip galvanized carbon steel scaffolding tube, BS1139 certified	Hot-dip galvanized general structural steel scaffolding tube
Outer Diameter	48.3 mm (1-1/2″ NPS, DN40)	48.3 mm (1-1/2″ NPS, DN40)	48.3 mm (1-1/2″ NPS, DN40)	48.3 mm (1-1/2″ NPS, DN40)
Wall Thickness Options	3.0 mm, 3.2 mm, 3.5 mm, 4.0 mm	3.2 mm (main), 3.5 mm, 4.0 mm	3.0 mm, 3.2 mm, 3.5 mm, 4.0 mm	3.0 mm, 3.2 mm
Typical Application	General building facade scaffolding, temporary support	European construction scaffolding, ring-lock systems, heavy-load projects	UK construction scaffolding, building access platforms	Indoor temporary support, light-duty scaffolding
Load Capability	Standard load-bearing capacity	High stable load, meets EN39 construction requirements	Medium to heavy load capacity	Light & medium load scenarios
Surface Treatment	Hot-dip galvanizing only	Hot-dip galvanizing only	Hot-dip galvanizing only	Hot-dip galvanizing only
Zinc Coating Weight	≥200 g/m²	≥200 g/m²	≥200 g/m²	≥200 g/m²
Corrosion Resistance	1–3 years outdoor service life	1–3 years outdoor service life	1–3 years outdoor service life	1–2 years outdoor service life
Applicable Standards	GB/T 13793, JGJ 130	BS EN 39, BS 1139	BS1139, GB/T 13793	EN 10025, GB/T 13793
Recommended Buyers	Domestic & global building contractors, scaffolding rental companies	EU construction companies, overseas engineering contractors	UK scaffolding importers, construction projects	General builders, temporary structure manufacturers
Customization Options	Length cutting, pipe end beveling & deburring	Length cutting, pipe end beveling & deburring	Length cutting, pipe end beveling & deburring	Length cutting

App Market

Reliable Steel Coil Solutions For Diverse Industrial Applications

Temporary Exhibition Stage Truss

Construction Working Platform

Coupler-Type Scaffolding for Building Exterior Wall Construction

Product Packaging

Secure Export Packaging For Safe Handling And Delivery

FAQs

What standard applies to S235JR galvanized scaffolding pipe?

It follows EN 10025 standard, with production inspection compliant with GB/T13793, suitable for light-duty structural temporary works.

What wall thickness options are available for S235JR scaffolding tube?

Available wall thickness: 3.0mm and 3.2mm, matching light and medium load applications.

Can you cut S235JR galvanized scaffolding pipe to custom lengths?

Yes, we support length cutting service according to client requirements.

What is the MOQ for S235JR galvanized scaffolding pipe?

MOQ is 5 metric tons.

Is S235JR scaffolding pipe suitable for long-term outdoor heavy-duty scaffolding?

It is recommended for indoor temporary support and light-duty projects. For heavy outdoor construction, we suggest EN39 S235GT or BS1139 St44 grade scaffolding pipe.
