201 Stainless Steel Flat Bar | GB/T 1220, 1Cr17Mn6Ni5N, 1.4372, SUS201

Cost-effective stainless alternative for indoor decorative projects
Good tensile strength & excellent formability for bending & cutting
Polishable surface available for decorative appearance
Stable dimension tolerance for precise fabrication
Ready stock, flexible cutting service for quick delivery

Product Overview

201 Stainless Steel Flat Bar (SUS201 / 1Cr17Mn6Ni5N / 1.4372) is a manganese-nickel austenitic stainless steel flat bar manufactured per GB/T1220 standard. It is a low-nickel grade stainless flat bar developed as an economical substitute for 304 stainless steel.

The product features solid rectangular profile, width range 10–250mm, thickness 2–40mm. Available surface finishes include 2B hot rolled pickled finish, HL hairline brushed finish and mirror polishing.

SUS201 flat bar can be processed by cutting, bending, punching and welding. It is widely applied in indoor architectural decoration, cabinet frames, kitchen utensils, indoor brackets and low-corrosion industrial components. It is NOT recommended for outdoor or chloride-rich corrosive environments.

We supply full mill test certificate, export seaworthy packing and customizable length for global buyers.

Stainless Steel Flat Bar

Chemical & Mechanical Property Snapshot

Grade	Equivalent Standard	C (%)	Cr (%)	Ni (%)	Mn (%)	Yield Strength Rp0.2 (MPa)	Tensile Strength Rm (MPa)	Elongation A (%)	Hardness HV
201	GB/T1220,1Cr17Mn6Ni5N,1.4372,SUS201	≤0.15	16.00–18.00	3.50–5.50	5.50–7.50	≥275	≥520	≥40	≤200

Detailed Technical Specifications

Item	Specification
Product Name	201 Stainless Steel Flat Bar
Material	201 Stainless Steel (SUS201 /1Cr17Mn6Ni5N /1.4372)
Shape	Rectangular Solid Bar
Width	10mm – 250mm
Thickness	2mm – 40mm
Surface Finish	2B Hot-Rolled Pickled, HL Hairline Brushed, Mirror Polished
Standard	GB/T 1220
Processing Methods	Cutting, Bending, Punching, Welding
Application Fields	Indoor decoration, kitchen utensils, indoor brackets, cabinet components, decorative trim
Quality Control	Mill Test Certificate including heat number, chemical composition and mechanical test results
Packing	Secure export packing to prevent scratches, dents and deformation
MOQ	5 Ton
Payment Terms	T/T, L/C at Sight
Delivery Time	7–15 working days after receiving deposit

Size Specification Table

Item	Specification
Profile	Rectangular solid flat bar
Width Range	10 mm, 12 mm, 15 mm, 20 mm, 25 mm, 30 mm, 40 mm, 50 mm, 60 mm, 80 mm, 100 mm, 120 mm, 150 mm, 180 mm, 200 mm, 250 mm
Thickness Range	2 mm, 3 mm, 4 mm, 5 mm, 6 mm, 8 mm, 10 mm, 12 mm, 15 mm, 20 mm, 25 mm, 30 mm, 35 mm, 40 mm
Standard Length	3000 mm, 5800 mm, 6000 mm; custom cut length available
Tolerance	Width tolerance: ±0.3 mm; Thickness tolerance: ±0.2 mm; Length tolerance: +10 / -0 mm
Surface Finish	2B, Hot-Rolled Pickled, 8K Mirror Finish, HL Hairline Brushed Finish
Available Grades	304, 304L, 316, 316L, 321, 310S, 430, 2205, 2507, 904L, 17-4PH

Product Comparison Table

Grade	Standard	Equivalent Grade	Density(g/cm³)	Yield Strength (MPa, Min)	Tensile Strength (MPa, Min)	Elongation (%)	Main Feature	Typical Application
201	GB/T 1220	1Cr17Mn6Ni5N /1.4372 / SUS201	7.93	275	520	40	Low nickel, cost-effective, moderate corrosion resistance	Decoration, kitchen utensils, indoor brackets
304	GB/T 1220	06Cr19Ni10 /1.4301 / SUS304	7.93	205	515	40	Excellent general corrosion resistance, easy fabrication	Food equipment, construction, chemical pipeline accessories
304L	GB/T 1220	022Cr19Ni10 /1.4307 / SUS304L	7.93	170	485	40	Low carbon, good intergranular corrosion resistance after welding	Welded parts, chemical equipment, pressure vessels

App Market

Reliable Steel Coil Solutions For Diverse Industrial Applications

Curtain Wall Decorative Strips

Corrosion-Resistant Grounding Flat Steel

Bent Parts for Equipment Enclosures

Product Packaging

Secure Export Packaging For Safe Handling And Delivery

FAQs

What is the difference between 201 and 304 stainless steel flat bar?

201 is low nickel, cost-saving grade with manganese replacement for nickel. Its corrosion resistance is weaker than 304. 201 is suitable for indoor dry environment; 304 is preferred for outdoor or humid working conditions.

What surface finishes can you supply for SUS201 flat bar?

We offer 2B pickled surface, HL hairline brushed and mirror polishing finish for decorative usage.

Can you cut 201 stainless flat bar to custom length?

Yes, we provide custom cutting service to meet your fabrication requirements.

What is the MOQ for 201 stainless steel flat bar?

MOQ is 5 tons. Mixed container with other stainless steel grades is acceptable.

Can 201 stainless flat bar be used for outdoor projects?

Not recommended. 201 grade will easily rust under rainy, salty or humid outdoor environments. Choose 304 or 316L for outdoor applications.
