Abrasion Resistant Steel Plate

Full grade gradient coverage from NM400 to NM600 and Hardox400~Hardox600, matching different wear intensity working conditions.
Complete size range: thickness 3~120mm, width 1500~2500mm, length 6000~12000mm, support customized cutting & processing service.
Excellent anti-abrasion & anti-impact performance, greatly extending service life of equipment wear parts and lowering equipment maintenance frequency.
Good machining, bending and welding performance, convenient for deep processing into hoppers, buckets, lining plates and other finished accessories.
Stable mill direct supply with complete material test documents, global logistics delivery to all industrial countries around the world.

Product Overview

Our abrasion resistant steel plate is a hot-rolled wear-resistant structural material designed for heavy friction and impact working environments. Manufactured according to GB/T24186, ASTM A606, and EN 10200 standards, it covers a wide range of wear grades from domestic NM series to international AR, HB, and Hardox series.

Available grades include NM400, NM450, NM500, NM550, NM600, AR400, AR450, AR500, HB400, Hardox 400, Hardox 450, Hardox 500, Hardox 550, and Hardox 600, meeting different wear intensity requirements in mining, construction machinery, and cement industries.

With specifications from 3–120mm thickness, customized cutting and forming services, and traceable material documentation, the wear resistant steel plate provides excellent abrasion resistance, impact performance, and reliable processing capability for manufacturing durable wear components.

Abrasion / Wear Resistant Steel Plate

Chemical & Mechanical Property Snapshot

Grade	Brinell Hardness (HBW)	C Max. (%)	Si Max. (%)	Mn Max. (%)	Cr Max. (%)	Yield Strength (MPa)	Tensile Strength (MPa)	Elongation A5 (%) Min.
NM400	360–420	0.22	0.70	1.60	0.80	900	1100–1400	10
NM450	420–480	0.25	0.70	1.60	1.00	950	1200–1500	9
NM500	470–530	0.30	0.70	1.60	1.20	1050	1300–1600	8
NM550	520–580	0.33	0.80	1.50	1.30	1100	1400–1700	7
NM600	570–630	0.35	0.80	1.50	1.40	1200	1500–1800	6
AR400	360–430	0.24	0.75	1.50	0.70	880	1100–1400	10
AR450	420–480	0.27	0.75	1.50	0.90	930	1200–1500	9
AR500	470–530	0.31	0.75	1.50	1.10	1030	1300–1600	8
HB400	370–430	0.23	0.70	1.60	0.75	890	1100–1400	10
Hardox 400	370–430	0.21	0.50	1.40	0.90	1000	1250–1500	10
Hardox 450	425–475	0.23	0.50	1.40	1.00	1050	1300–1600	9
Hardox 500	470–530	0.27	0.50	1.40	1.10	1100	1400–1700	8
Hardox 550	525–575	0.30	0.50	1.30	1.20	1150	1450–1750	7
Hardox 600	570–640	0.32	0.50	1.30	1.30	1250	1550–1850	6
Note: Chemical composition and mechanical properties are typical values for reference only. Actual values shall comply with the mill test certificate. Hardness testing shall be performed on the surface, excluding the decarburized layer.

Detailed Technical Specifications

Category	Item
Product Name	Abrasion / Wear Resistant Steel Plate
Product Type	Hot Rolled Wear Resistant Structural Steel Plate
Applicable Standards	GB/T24186, ASTM A606, EN 10200
Material Application	Designed for heavy friction and impact working environments
Domestic Grade Series	NM400, NM450, NM500, NM550, NM600
American Grade Series	AR400, AR450, AR500
European Grade Series	HB400, Hardox 400, Hardox 450, Hardox 500, Hardox 550, Hardox 600
Thickness Range	3–120mm
Width Range	1500–2500mm
Length Range	6000–12000mm
Heat Treatment	Quenched & Tempered (Q&T)
Performance Features	Excellent abrasion resistance, impact resistance, uniform hardness, and stable mechanical performance
Processing Capability	Customized cutting, blanking, and forming according to equipment drawings
Fabrication Performance	Good weldability, machining performance, and forming capability
Quality Documentation	Traceable material certificates and product test documents
Main Applications	Mining chutes, hoppers, crusher liners, excavator buckets, bulldozer blades, cement fan blades, and separator liners
MOQ	5 Metric Tons
Trade Terms	FOB, CFR, CIF, DAP, DDP, EXW
Payment Methods	T/T, L/C at sight; negotiable for bulk mining project orders

Product Comparison Table

Grade Series	Typical Grades	Performance Characteristics	Recommended Applications
NM Series Wear Resistant Steel	NM400 / NM450 / NM500 / NM550 / NM600	Different hardness levels for various wear intensity conditions	Mining equipment, crushers, industrial wear parts
AR Series Wear Resistant Steel	AR400 / AR450 / AR500	High abrasion resistance and impact performance	Heavy machinery and wear-resistant components
HB Series Wear Resistant Steel	HB400	European standard wear-resistant steel grade	Industrial equipment and structural wear applications
Hardox Series Wear Resistant Steel	Hardox 400 / 450 / 500 / 550 / 600	High hardness with excellent wear resistance and toughness	Excavator buckets, liners, mining and construction equipment
Customized Wear Resistant Plate	Custom processed plates	Cutting, blanking, and forming based on drawings	Finished wear-resistant components

App Market

Reliable Steel Coil Solutions For Diverse Industrial Applications

Mining

cement

Construction

Product Packaging

Secure Export Packaging For Safe Handling And Delivery

FAQs

What is abrasion resistant steel plate?

Abrasion resistant steel plate is a wear-resistant structural steel material designed for equipment exposed to heavy friction, impact, and material abrasion.

What grades are available for wear resistant steel plate?

Available grades include NM400–NM600, AR400–AR500, HB400, and Hardox 400–600 series for different wear conditions.

Where is abrasion resistant steel plate used?

It is widely used in mining chutes, hoppers, crusher liners, excavator buckets, bulldozer blades, cement fan blades, and separator liners.

Can wear resistant steel plates be customized?

Yes. Cutting, blanking, and forming services can be provided according to customer equipment drawings and processing requirements.

How does wear resistant steel improve equipment performance?

The material reduces abrasion damage, extends wear component service life, and helps reduce maintenance frequency in demanding industrial applications.
