DR8 Double Reduced Electrolytic Tinplate ETP | Thin Wall Rigid Can Tin Plate

Ultra-high rigidity for lightweight thin-wall can design
Excellent dimensional stability after stamping
Double-sided pure tin coating for reliable corrosion protection
Lower material thickness saves packaging cost
Suitable for rigid lid and thin-wall container forming

Product Overview

DR8 Electrolytic Tinplate (ETP) is double-reduced ultra-thin low carbon steel substrate electroplated pure tin on both sides, produced to GB/T2520 and ASTM A623 standards.DR8 belongs to DR temper series, HR30T hardness 74-80, much higher stiffness than single reduced SR grades. It is designed for thin-wall lightweight cans and rigid packaging lids, allowing thinner steel gauge while maintaining structural strength. Tin coating weight 1.1~11.2 g/m², surface finish: Bright, Stone, Silver, Matte. DR8 ETP can be formed by stamping for thin-wall metal containers, compatible with printing and internal protective coating. We supply DR8 ETP coil and sheet for B2B packaging manufacturers, mill test certificates available

Electrolytic Tinplate (ETP)

Chemical & Mechanical Property Snapshot

Grade	C (Max, %)	Mn (Max, %)	P (Max, %)	S (Max, %)	Si (Max, %)	HR30T Hardness	Min Elongation
DR8	0.12	0.12	0.020	0.050	0.02	74-80	5%

Detailed Technical Specifications

Category	Item
Product Name	DR8 Electrolytic Tinplate (ETP)
Product Type	Double Reduced Electrolytic Tinplate
Manufacturing Standard	GB/T 2520 / ASTM A623
Steel Type	Ultra-Thin Low-Carbon Steel Sheet
Temper Grade	DR8 (Double Reduced DR)
Tin Coating	1.1–11.2 g/m²
Annealing	BA / CA
Surface Finishes	Bright / Stone / Silver / Matte
Surface Treatment	Electrolytic Tin Coating on Both Sides
Key Properties	High Stiffness, Thin Gauge, Corrosion Resistant, Dimensional Stability
Forming Performance	Suitable for Thin-Wall Lightweight Can & Rigid Lid Forming
Main Applications	Thin-Wall Food Cans, Lightweight Containers, Rigid Can Lids
Packaging Function	Printing, Internal Coating, Lightweight Metal Packaging
MOQ	5 Ton
Payment Terms	T/T, L/C at Sight
Delivery Time	7–15 working days after receiving deposit
Package	Waterproof paper + plastic film + wooden pallet, seaworthy export packing

Product Comparison Table

Item	DR8 DR Tinplate	Other DR Grades (DR7/DR9/DR9M)
Temper	DR8 Double Reduced	DR7 / DR9 / DR9M Double Reduced
HR30T Hardness	74-80	DR7:70-76; DR9:78-84; DR9M:80-86
Elongation	5%	3%~6%
Core Characteristic	High rigidity for thin-wall lightweight cans	DR7 lower hardness; DR9/DR9M extra high stiffness
Forming Suitability	Thin-wall can & rigid lid stamping	DR7 moderate stamping; DR9/DR9M heavy rigid forming
Typical Use	Lightweight thin-wall cans, rigid packaging lids	DR7 thin containers; DR9/DR9M ultra-rigid can parts
Surface Options	Bright / Stone / Silver / Matte	Bright / Stone / Silver / Matte

App Market

Reliable Steel Coil Solutions For Diverse Industrial Applications

Food Can Body ETP

Aerosol Can ETP

Paint Bucket ETP

Milk Powder Can ETP

Product Packaging

Secure Export Packaging For Safe Handling And Delivery

FAQs

What is DR8 double reduced tinplate?

DR8 is double reduced ETP tinplate, ultra high rigidity thin gauge tinplate for lightweight thin wall cans.

What is HR30T hardness for DR8 tinplate?

HR30T hardness 74-80, minimum elongation 5%.

What is the difference between DR8 and SR T grades?

DR8 double reduced tinplate has far higher stiffness, used for thin-wall lightweight can production.

Can DR8 ETP be printed?

Yes, DR8 grade supports offset printing and internal coating for packaging decoration.

What’s the MOQ of DR8 electrolytic tinplate?

MOQ 5 tons, coil or sheet form available.
