T1 Tin Free Steel Coil TFS/TMBP | Electrolytic Chromium Coated ECCS Steel Coil

Excellent stamping & deep drawing performance
Superior paint and ink adhesion property
Stable chromium coating, uniform surface
Low carbon substrate with good ductility
Compliant with ASTM, JIS, EN & GB standards

Product Overview

T1 Tin Free Steel Coil (TFS/TMBP / ECCS) is low-carbon cold rolled steel substrate with electrolytic chromium coating, including metallic chromium layer and chromium hydrated oxide layer. T1 is the softest temper grade in TFS series, featuring great ductility and formability. It can be supplied in TFS-S single side or TFS-D double side chromium coating. Thickness range 0.15–0.45mm, standard coil width 800–1050mm, custom slitting service available. Widely used for crown caps, easy open ends, cosmetic packaging, twist-off food caps and printed metal boxes.

Tin Free Steel Coil - TFS/TMBP

Chemical & Mechanical Property Snapshot

Grade	C Max (%)	Mn Max (%)	P Max (%)	S Max (%)	Yield Strength (MPa)	Tensile Strength (MPa)	Elongation (%)	Hardness (HR30T)
T1	0.12	0.60	0.020	0.050	210–290	310–390	≥27	46–52

Detailed Technical Specifications

Item	Specification
Product Name	T1 Tin Free Steel Coil – TFS/TMBP
Alternative Name	T1 ECCS Electrolytic Chromium Coated Steel
Steel Substrate	Low-carbon cold rolled steel
Surface Treatment	Electrolytic chromium coating
Metallic Chromium Coating	70–150 mg/m²
Chromium-Hydrated-Oxide Layer	5–15 mg/m²
Coating Configuration	TFS-S / TFS-D
Temper Grade	T1
Thickness	0.15–0.45 mm
Standard Coil Width	800–1050 mm
Slitting	Custom narrow-width slitting available
Applicable Standards	ASTM A624/A624M, JIS G3315, EN 10202, GB/T 2520
Quality Documentation	Mill Test Certificate covering coating weight, mechanical properties and chemical composition
Packing	Seaworthy export-grade packing
MOQ	5 Ton
Payment Terms	T/T, L/C at Sight
Delivery Time	7–15 working days after receiving deposit
Package	Waterproof paper + galvanized steel strap + seaworthy export wooden pallet

Product Comparison Table

Specification	T1 TFS-S	T1 TFS-D	T1 ETP Tinplate
Material Type	Tin Free Steel	Tin Free Steel	Electrolytic Tinplate
Surface Treatment	Electrolytic Chromium Coating	Electrolytic Chromium Coating	Electrolytic Tin Coating
Coating Sides	Single-Sided	Double-Sided	Tin Coating on Both Sides
Surface Structure	Metallic Chromium + Chromium-Hydrated Oxide	Metallic Chromium + Chromium-Hydrated Oxide	Tin Coating
Paint / Printing Adhesion	Excellent	Excellent	Good, depending on application
Yield Strength Range	210–290 MPa	210–290 MPa	210–290 MPa
Typical Selection Factor	Single side chromium coating, deep drawing parts	Double side chromium coating, deep drawing packaging	Tin coating required for food can welding
Thickness Range	0.15–0.45 mm	0.15–0.45 mm	0.15–0.45 mm
Standard Width	800–1050 mm	800–1050 mm	800–1050 mm
Typical Applications	Crown caps, easy-open ends, cosmetic packaging	Crown caps, printed metal boxes, twist-off caps	Food cans, milk powder cans, welded aerosol cans
Important Boundary	Not suitable for hermetic sealed welding	Not suitable for hermetic sealed welding	Suitable for sealed can welding

App Market

Reliable Steel Coil Solutions For Diverse Industrial Applications

Lithium Battery Steel Casing

Cosmetic Packaging Boxes

Crown Caps for Beer and Beverages

Product Packaging

Secure Export Packaging For Safe Handling And Delivery

FAQs

What is T1 grade TFS steel coil used for?

T1 TFS is the soft temper grade, ideal for deep drawing applications such as bottle crown caps, cosmetic metal boxes and easy-open ends.

Can T1 TFS be welded for hermetic food cans?

No. TFS (ECCS) is not designed for hermetic sealed welding. Use ETP tinplate if welding is required.

What coating options for T1 TFS coil?

We supply TFS-S single sided chromium coating and TFS-D double sided chromium coating for T1 grade.

What is MOQ for T1 Tin Free Steel Coil?

Our minimum order quantity is 5 tons.

Can you provide slitting service for T1 TFS coil?

Yes, custom narrow width slitting service is available to meet customer size requirements.
