A36 W-Beam, Q235B / S235JR Wide Flange Beam ASTM A6 A36

Excellent weldability and easy field fabrication
Cost-effective American standard carbon structural steel
Balanced ductility and stable mechanical performance
Complete W-series size range for flexible project selection
Multiple surface treatment options for different environments

Product Overview

A36 hot rolled W-Beam is the classic American standard wide flange structural steel, equivalent grades Q235B (GB/T11263) and S235JR (EN10025). It is produced according to ASTM A6, ASTM A36, GB/T11263 and EN10025 specifications.

W-Beam features wide parallel flanges, offering superior bending resistance and torsional stability compared to standard I-beam. A36 grade is low carbon steel with great plasticity and outstanding weldability. It supports cutting, drilling, beveling and welding without complex heat treatment.

This grade wide flange beam is widely used for general construction, secondary support frames, non-heavy load building structures and temporary engineering projects. We supply full W-series range from W4×13 up to W44×335. Surface options include hot rolled black finish, shot blasting, pickling, anti-corrosion paint and hot-dip galvanizing. Custom cut-to-length service available.

W-Beam

Chemical & Mechanical Property Snapshot

Grade	Standard	C Max (%)	Mn (%)	P Max (%)	S Max (%)	Si (%)	Yield Strength MPa	Tensile Strength MPa	Elongation %
A36	ASTM A36	0.25	0.80–1.20	0.040	0.050	0.40 max	≥250	400–550	≥20

Detailed Technical Specifications

Technical Item	Detailed Specification
Product Name	A36 W-Beam
Product Type	American Wide-Flange Hot-Rolled Structural Steel
Level 1 Category	Structural Section/Profile
Level 2 Category	H & I & W Beam
Level 3 Category	W-Beam
Applicable Standards	ASTM A6, ASTM A36, GB/T11263, EN10025
W-Series Range	W4×13~W44×335
Common W-Series Models	W6×15, W6×20, W8×18, W8×21, W8×24, W10×22, W10×30, W10×39, W12×26, W12×35, W12×40, W12×50, W14×34, W14×43, W14×53, W14×68, W16×36, W16×40, W16×50, W16×67, W18×40, W18×50, W18×60, W18×71, W21×44, W21×55, W21×68, W21×83, W24×55, W24×68, W24×76, W24×84, W24×103, W27×84, W27×94, W27×102, W30×90, W30×108, W30×116, W30×124, W36×135, W36×150, W40×149, W44×335
Equivalent Grades	Q235B, S235JR
Standard Lengths	6 m / 12 m
Custom Length	3–18 m
Cut-to-Length	Available
Original Surface	Hot-Rolled Black Finish
Surface Treatment	Shot-Blasting, Pickling, Anti-Corrosive Paint Coating, Hot-Dip Galvanizing, Fire-Retardant Coating
Galvanizing Coating Weight	120–275 g/m²
Fabrication Services	End Beveling, Drilling, Cutting, Welding, Component Assembly
Drawing-Based Processing	Available according to customer drawings
Quality Documentation	Official Mill Test Certificate
MTC Content	Chemical Composition and Mechanical Properties
Packing	Seaworthy Export Packing
Building Applications	Secondary building columns, roof girders, light commercial building frames
Bridge Applications	Auxiliary bridge supports, non-primary cross beams
Industrial Applications	Light factory steel frames, equipment base, storage-rack upright columns
New Energy Applications	Low-load photovoltaic support frames
MOQ	5 Ton
Payment Terms	T/T, L/C at Sight
Delivery Time	7–15 working days after receiving deposit

Dimension Table

Designation	Height (H) mm	Flange Width (B) mm	Web Thickness (tw) mm	Flange Thickness (tf) mm	Weight kg/m	Section Area cm²
W4×13	101.6	101.6	5.8	7.6	19.3	24.6
W6×15	152.4	101.6	5.6	7.1	22.3	28.4
W6×20	152.4	152.4	6.6	9.1	29.8	37.9
W8×18	203.2	101.6	5.8	7.6	26.8	34.2
W8×21	203.2	133.4	6.1	7.9	31.2	39.8
W8×24	203.2	165.1	6.1	8.3	35.8	45.7
W10×22	254.0	101.6	6.1	8.4	32.7	41.7
W10×30	254.0	146.0	6.6	9.9	44.6	56.9
W10×39	254.0	165.1	9.1	11.8	57.9	73.8
W12×26	304.8	127.0	6.1	8.4	38.6	49.2
W12×35	304.8	165.1	6.6	9.9	52.0	66.2
W12×40	304.8	190.5	7.2	10.2	59.2	75.4
W12×50	304.8	203.2	9.1	12.6	74.0	94.4
W14×34	355.6	165.1	6.6	9.7	50.7	64.7
W14×43	355.6	177.8	7.9	11.2	64.0	81.6
W14×53	355.6	203.2	9.1	12.8	78.8	100.4
W14×68	355.6	254.0	10.2	14.7	101.2	128.8
W16×36	406.4	152.4	6.6	9.9	53.5	68.2
W16×40	406.4	177.8	6.6	10.2	59.2	75.4
W16×50	406.4	203.2	7.9	11.8	74.0	94.4
W18×50	457.2	190.5	7.9	11.8	74.0	94.4
W18×60	457.2	203.2	9.1	13.5	89.0	113.6
W18×71	457.2	254.0	10.2	14.7	105.4	134.6
W21×44	533.4	165.1	7.1	10.2	65.3	83.4
W21×55	533.4	190.5	8.1	12.1	81.7	104.3
W21×68	533.4	210.8	9.7	13.8	101.2	128.8
W21×83	533.4	254.0	10.9	16.3	123.5	157.2
W24×55	609.6	177.8	7.9	11.2	81.7	104.3
W24×68	609.6	203.2	9.1	13.0	101.2	128.8
W24×84	609.6	228.6	10.5	15.4	124.8	158.9
W24×103	609.6	254.0	12.6	17.7	152.9	194.8
W27×84	685.8	228.6	10.2	14.7	124.8	158.9
W27×94	685.8	254.0	10.9	15.7	139.7	178.1
W27×107	685.8	254.0	12.3	17.4	159.1	202.8
W30×90	762.0	210.8	11.2	16.3	133.7	170.6
W30×108	762.0	254.0	11.9	17.4	160.6	204.7
W30×124	762.0	254.0	13.8	19.6	184.3	234.8
W36×135	914.4	304.8	14.0	20.1	200.7	255.8
W36×150	914.4	304.8	15.9	21.7	223.0	284.2
W40×149	1016.0	304.8	14.4	20.3	221.5	282.3
W44×335	1117.6	419.1	25.0	41.3	498.9	636.2

Product Comparison Table

W-Beam Grade	Equivalent Grade	Applicable Standard	Yield Strength MPa	Tensile Strength MPa	Typical Application	Selection Consideration
A36 W-Beam	Q235B / S235JR	ASTM A36, GB/T11263, EN10025	≥250	400–550	General construction, secondary supports, non-load heavy structures	Low carbon, excellent weldability; ideal for general structural fabrication

App Market

Reliable Steel Coil Solutions For Diverse Industrial Applications

North American Factory Building Frame

North American Highway Bridges

Main Column for Steel Structure Residential Buildings

Product Packaging

Secure Export Packaging For Safe Handling And Delivery

FAQs

What is the equivalent grade of A36 W-Beam?

A36 W-Beam is equivalent to Chinese Q235B and European S235JR wide flange beam.

What is the mechanical property of A36 W-Beam?

Minimum yield strength ≥250 MPa, tensile strength ranges from 400 to 550 MPa, minimum elongation ≥20%.

What standards apply for A36 W-Beam?

Our A36 W-Beam complies with ASTM A6, ASTM A36, GB/T11263 and EN10025. Mill Test Certificate (MTC) can be provided.

Can I get custom cut A36 W-Beam?

Yes, we support cut-to-length service, custom length from 3m to 18m is available. We also provide fabrication including drilling, beveling and welding.

What are the main applications for A36 W-Beam?

It is widely used for general construction, secondary support frames, light commercial building structures, auxiliary bridge supports and low-load industrial & photovoltaic structures.
