CGCC PPGI Prepainted Galvanized Steel Sheet | Color Coated GI Steel Plate

CGCC substrate delivers excellent bending performance for roll forming and profiling
Multiple paint options PE/SMP/HDP/PVDF, long service life for outdoor building projects
RAL full color palette & customizable gloss, smooth/embossed surface available
Hot-dip galvanized GI base provides stable sacrificial anti-corrosion protection
Firm paint adhesion, no peeling during stamping, bending and cutting processing

Product Overview

CGCC PPGI Prepainted Galvanized Steel Sheet, also known as color coated GI steel plate, adopts CGCC low-carbon galvanized steel as substrate. It is manufactured by applying organic paint coating on hot-dip galvanized steel through continuous coating and curing process.

CGCC is the commercial forming grade, with outstanding ductility, designed for general cold forming operations. The galvanized GI substrate offers reliable rust protection. Available coating structure includes 2/1 and 2/2. Four paint systems: PE, SMP, HDP, PVDF for different service life requirements.

This CGCC PPGI supports standard RAL colors and custom color matching. Gloss can be adjusted from high-gloss, semi-gloss, low-gloss to matte. Surface finish options include smooth, orange peel, wood grain, stone grain. It is widely used for factory roof panels, wall cladding, sandwich panel skins, rolling shutters, agricultural greenhouse panels and interior decoration profiles.
Thickness range: 0.20mm ~1.2mm; Width: 700–1250mm, supplied in coil or cut flat sheet form.

Prepainted Steel Sheet - PPGI/PPGL

Chemical & Mechanical Property Snapshot

Grade	C Max (%)	Mn Max (%)	P Max (%)	S Max (%)	Tensile Strength (MPa)	Yield Strength (MPa)	Elongation (%)
CGCC	0.12	0.50	0.020	0.025	270–410	140–300	≥24

Detailed Technical Specifications

Category	Item
Product Name	CGCC PPGI Prepainted Galvanized Steel Sheet / Color Coated GI Steel Plate
Product Type	Prepainted Galvanized Steel (PPGI)
Substrate	Hot-dip Galvanized Steel GI, CGCC grade
Base Grade	CGCC
Zinc Coating Weight	Z40, Z60, Z80, Z100, Z120, Z140, Z275
Coating Structure	2/1, 2/2
Paint System	PE, SMP, HDP, PVDF
Processing	Bending, Profiling, Roll forming, Stamping, Cutting
Supply Form	Prepainted steel coil or cut flat sheet
Thickness	0.20mm – 1.2mm
Width	700mm – 1250mm
Main Applications	Factory roof panels, wall cladding, sandwich panels, rolling shutters, agricultural greenhouses, interior decorative panels
Color Standard	RAL, Pantone, custom color matching
Gloss Options	High gloss, Semi-gloss, Low gloss, Matte
Surface Finish	Smooth, Orange Peel, Wood Grain, Stone Grain
Quality Documents	Mill Test Certificate, third-party inspection optional
MOQ	Custom color MOQ negotiable
Payment Terms	T/T, L/C at Sight
Delivery Time	7–15 working days after deposit
Package	Waterproof paper + plastic film + wooden pallet, seaworthy export packing

Available Colors & Finishes – Prepainted Steel Sheet PPGI / PPGL

We offer prepainted steel sheet (PPGI) and prepainted galvanized steel sheet (PPGL) in a wide range of standard colors, gloss levels and surface finishes. Colors can be selected according to RAL standards, and custom color matching is available for special project requirements. Color consistency is controlled during coating, curing and inspection to reduce chromatic aberration in mass production.

Popular Standard Colors for PPGI / PPGL

Color Family	RAL Code	Color Name	Common Applications
White	RAL 9010	Pure White	Roofing, wall panels, clean rooms, appliances
White	RAL 9016	Traffic White	Building facades, sandwich panels, interior panels
White	RAL 9003	Signal White	Decoration panels, equipment shells, lightweight panels
Grey	RAL 7035	Light Grey	Industrial buildings, warehouses, partition panels
Grey	RAL 7016	Anthracite Grey	Modern facades, trim panels, architectural profiles
Grey	RAL 7004	Signal Grey	Steel structure buildings, workshops, silos
Grey	RAL 7024	Graphite Grey	Heavy industrial buildings, equipment enclosures
Black	RAL 9005	Jet Black	Facade trim, edge panels, decorative profiles
Black	RAL 9017	Traffic Black	Industrial cladding, structural parts
Blue	RAL 5015	Sky Blue	Industrial roofs, workshop walls, agricultural buildings
Blue	RAL 5010	Gentian Blue	Factories, warehouses, steel structure buildings
Blue	RAL 5005	Signal Blue	Cladding panels, equipment covers
Red	RAL 3009	Oxide Red	Agricultural buildings, roof sheets, warning parts
Red	RAL 3020	Traffic Red	Warning panels, architectural trim
Red	RAL 3011	Brown Red	Industrial buildings, special profiles
Green	RAL 6005	Moss Green	Farm buildings, garden enclosures, rural roofs
Green	RAL 6018	Yellow Green	Decorative panels, landscape buildings
Green	RAL 6029	Mint Green	Interior panels, appliance panels
Brown	RAL 8017	Chocolate Brown	Residential roofs, villa panels, decorative facades
Brown	RAL 8004	Copper Brown	Industrial buildings, roof systems
Beige / Cream	RAL 1015	Light Ivory	Interior panels, ceilings, decorative profiles
Beige / Cream	RAL 1001	Beige	Building facades, housing projects
Orange	RAL 2004	Pure Orange	Warning cladding, equipment panels
Yellow	RAL 1023	Traffic Yellow	Warning parts, safety-related panels

Gloss Level Options

Gloss Type	Gloss Range	Description	Recommended Applications
High Gloss	≥ 70°	Bright surface, strong reflection	Appliance panels, furniture boards, indoor decoration
Semi-Gloss	40°–70°	Balanced shine, good appearance	General roofing, wall cladding, steel structure buildings
Low Gloss	20°–40°	Soft reflection, less glare	Facades, industrial buildings, noise reduction panels
Matte	< 20°	Very low reflection, modern look	Architectural panels, premium facade projects

Surface Finish Options

Finish Type	Description	Recommended Applications
Smooth	Smooth painted surface with a clean appearance	Roofing sheets, wall panels, sandwich panels
Matte Finish	Low-gloss, anti-glare surface with a modern visual effect	Building facades, industrial cladding
Orange Peel	Fine textured surface that helps hide minor scratches	Bending profiles, roofing, general construction
Wood Grain	Decorative wood imitation pattern	Interior panels, doors, furniture boards
Stone Grain	Stone-like textured finish	Decorative facades, wall cladding
Metallic / Pearl	Metallic reflective effect	High-end architectural panels, special design projects

Color Selection Guide by Application

Application	Recommended Color Series	Recommended Finish
Roofing Sheet	White, Grey, Blue, Green, Brown	Smooth / Orange Peel
Wall Cladding	White, Grey, Black, Blue, Green	Smooth / Matte
Sandwich Panel	White, Light Grey, Traffic White	Smooth
Industrial Building	Light Grey, Anthracite Grey, Sky Blue	Semi-Gloss / Low Gloss
Agricultural Building	Moss Green, Oxide Red, Sky Blue	Orange Peel
Residential / Villa Panel	Brown, Green, White, Beige	Smooth / Matte
Decoration Panel	White, Black, Grey, Wood Grain	Smooth / Wood Grain
Equipment Shell	White, Grey, Blue, Orange	High Gloss / Smooth

Important Notes for Color Ordering

Confirm the color standard**: Please specify RAL number, Pantone number or physical sample.

Check gloss requirement**: The same color will look different under high gloss, semi-gloss or matte finish.

Coating system matters**: PE, SMP, HDP and PVDF may affect final color appearance and weather resistance.

Color difference exists**: There may be slight color variation between different batches and between screen display and actual steel sheet.

Pre-production confirmation**: We recommend confirming a physical color swatch or trial sample before mass production.

Project specific colors**: For architectural projects, color grouping and color separation requirements should be confirmed in advance.

Product Comparison Table

Product Option	Substrate Grade	Coating Structure	Paint Type	Best Application Scenario
CGCC PPGI PE	CGCC GI	2/1 / 2/2	PE	Indoor & mild outdoor, low budget construction
CGCC PPGI SMP	CGCC GI	2/1 / 2/2	SMP	Medium weather resistance, warehouse roofing
CGCC PPGI HDP	CGCC GI	2/1 / 2/2	HDP	Long-term outdoor factory wall & roof
CGCC PPGI PVDF	CGCC GI	2/1 / 2/2	PVDF	Harsh outdoor environment, high-end facade
TDC51D+AZ PPGL	TDC51D+AZ Aluzinc GL	2/1 / 2/2	PE/SMP/HDP/PVDF	Coastal high humidity environment

App Market

Reliable Steel Coil Solutions For Diverse Industrial Applications

Industrial Factory Panels PPGI Steel

Cold Storage Panels PPGI Steel

Rolling Shutters PPGI Steel

Container Sheets PPGI Steel

Product Packaging

Secure Export Packaging For Safe Handling And Delivery

FAQs

What is CGCC PPGI used for?

CGCC PPGI is general forming grade prepainted galvanized steel, mainly for industrial roof, wall cladding, sandwich panel, greenhouse and light forming parts.

What zinc coating weight options do you offer for CGCC PPGI?

We provide Z40, Z60, Z80, Z100, Z120, Z140 and Z275 zinc coating weight. Higher Z value means better corrosion resistance.

What paint type should I select for my factory roof?

SMP is economical for regular factory roof; HDP is recommended for longer outdoor service life; PVDF is for strict weather resistance requirement.

Can you send color swatch sample before mass production?

Yes, physical color panel or swatch can be provided for color confirmation before production. Color tolerance AE ≤2.0 for standard orders.

Can CGCC PPGI be bent and roll formed without paint peeling?

Yes. CGCC grade has good ductility. Proper paint system guarantees no coating peeling during bending and profiling.

What is the MOQ for custom RAL color CGCC PPGI?

MOQ for custom color is negotiable, subject to thickness, width and total order quantity. Stock standard colors support smaller trial order.
