G550 Prepainted Steel Sheet PPGI/PPGL | High Tensile Color Coated Plate

PE PVDF HDP SMP Prepainted Steel Sheet PPGI PPGL | Polyester & Fluorocarbon Color Coated Steel

Four coating grades available to match different project lifespans & budget
Excellent coating adhesion for roll forming, bending & corrugated processing
Superior UV & anti-chalking performance, reduce maintenance cost
PPGI / PPGL substrate optional for inland or coastal corrosive environment
Strict coating thickness inspection, consistent quality for bulk export orders

Product Overview

PE, SMP, HDP and PVDF prepainted steel sheet (PPGI & PPGL) are color coated metal products with different organic coating systems on hot-dip galvanized or galvalume steel substrates. Each coating grade has unique weather resistance, color retention and service life to satisfy diverse global construction and industrial projects.

PE (Polyester) is the economical option with good flexibility and wide color selection, widely adopted for normal inland roofing and wall cladding. SMP (Silicone Modified Polyester) delivers better heat resistance and gloss retention than standard PE, suitable for buildings exposed to strong sunlight. HDP (High Durable Polyester) offers upgraded anti-UV and anti-fading performance, designed for medium-long warranty commercial facades. PVDF (Polyvinylidene Fluoride / Fluorocarbon) owns top-tier weather & salt spray resistance, ideal for coastal, high-corrosion and premium architectural projects, with long-term color stability over 20 years.

We provide customized thickness, width, zinc/aluminum-zinc coating weight, top & back paint thickness. Surface finishes include smooth, matte, wrinkle, wood grain and marble texture. All products can pass third-party inspection, comply with EN, ASTM, JIS standards. Widely used for roof panels, wall cladding, prefabricated houses, warehouse, curtain wall, agricultural buildings and home appliance shells. Export packing with waterproof paper & steel strapping to protect sheets during sea shipment.

Prepainted Steel Sheet - PPGI/PPGL

Chemical & Mechanical Property Snapshot

Coating Grade	Coating Resin	Typical Service Life	Top Coat Thickness	Flexibility	Salt Spray Resistance
PE	Polyester	7–10 years	15–20μm	Excellent	Moderate
SMP	Silicone Modified Polyester	10–15 years	20–25μm	Good	Moderate-High
HDP	High Durable Polyester	15–20 years	25–30μm	Good	High
PVDF	PVDF Fluorocarbon	20–25+ years	25–35μm	Fair	Excellent

Detailed Technical Specifications

Item	Specification
Product Name	PE / SMP / HDP / PVDF Prepainted Steel Sheet (PPGI / PPGL)
Base Substrate	DX51D+Z (PPGI Galvanized), DX51D+AZ (PPGL Galvalume)
Thickness	0.12mm – 1.2mm
Width	600mm – 1250mm, custom slitting available
Zinc / Al-Z Coating	Z40~Z275 g/m², AZ50~AZ150 g/m²
Paint Structure	2/1 or 2/2 coating system
Back Coating	Epoxy primer / Polyester 5–10μm
Surface Finish	Smooth, Matte, Wrinkle, Woodgrain, Marble pattern
Standard	EN 10169, ASTM A755, JIS G3312
Application	Roofing, wall cladding, prefab building, facade, industrial enclosure
Certificate	ISO9001, SGS, BV third-party inspection available

Quality Documents	Mill Test Certificate, third-party inspection optional
MOQ	Custom color MOQ negotiable
Payment Terms	T/T, L/C at Sight
Delivery Time	7–15 working days after deposit
Package	Waterproof paper + plastic film + wooden pallet, seaworthy export packing

Available Colors & Finishes – Prepainted Steel Sheet PPGI / PPGL

We offer prepainted steel sheet (PPGI) and prepainted galvanized steel sheet (PPGL) in a wide range of standard colors, gloss levels and surface finishes. Colors can be selected according to RAL standards, and custom color matching is available for special project requirements. Color consistency is controlled during coating, curing and inspection to reduce chromatic aberration in mass production.

Popular Standard Colors for PPGI / PPGL

Color Family	RAL Code	Color Name	Common Applications
White	RAL 9010	Pure White	Roofing, wall panels, clean rooms, appliances
White	RAL 9016	Traffic White	Building facades, sandwich panels, interior panels
White	RAL 9003	Signal White	Decoration panels, equipment shells, lightweight panels
Grey	RAL 7035	Light Grey	Industrial buildings, warehouses, partition panels
Grey	RAL 7016	Anthracite Grey	Modern facades, trim panels, architectural profiles
Grey	RAL 7004	Signal Grey	Steel structure buildings, workshops, silos
Grey	RAL 7024	Graphite Grey	Heavy industrial buildings, equipment enclosures
Black	RAL 9005	Jet Black	Facade trim, edge panels, decorative profiles
Black	RAL 9017	Traffic Black	Industrial cladding, structural parts
Blue	RAL 5015	Sky Blue	Industrial roofs, workshop walls, agricultural buildings
Blue	RAL 5010	Gentian Blue	Factories, warehouses, steel structure buildings
Blue	RAL 5005	Signal Blue	Cladding panels, equipment covers
Red	RAL 3009	Oxide Red	Agricultural buildings, roof sheets, warning parts
Red	RAL 3020	Traffic Red	Warning panels, architectural trim
Red	RAL 3011	Brown Red	Industrial buildings, special profiles
Green	RAL 6005	Moss Green	Farm buildings, garden enclosures, rural roofs
Green	RAL 6018	Yellow Green	Decorative panels, landscape buildings
Green	RAL 6029	Mint Green	Interior panels, appliance panels
Brown	RAL 8017	Chocolate Brown	Residential roofs, villa panels, decorative facades
Brown	RAL 8004	Copper Brown	Industrial buildings, roof systems
Beige / Cream	RAL 1015	Light Ivory	Interior panels, ceilings, decorative profiles
Beige / Cream	RAL 1001	Beige	Building facades, housing projects
Orange	RAL 2004	Pure Orange	Warning cladding, equipment panels
Yellow	RAL 1023	Traffic Yellow	Warning parts, safety-related panels

Gloss Level Options

Gloss Type	Gloss Range	Description	Recommended Applications
High Gloss	≥ 70°	Bright surface, strong reflection	Appliance panels, furniture boards, indoor decoration
Semi-Gloss	40°–70°	Balanced shine, good appearance	General roofing, wall cladding, steel structure buildings
Low Gloss	20°–40°	Soft reflection, less glare	Facades, industrial buildings, noise reduction panels
Matte	< 20°	Very low reflection, modern look	Architectural panels, premium facade projects

Surface Finish Options

Finish Type	Description	Recommended Applications
Smooth	Smooth painted surface with a clean appearance	Roofing sheets, wall panels, sandwich panels
Matte Finish	Low-gloss, anti-glare surface with a modern visual effect	Building facades, industrial cladding
Orange Peel	Fine textured surface that helps hide minor scratches	Bending profiles, roofing, general construction
Wood Grain	Decorative wood imitation pattern	Interior panels, doors, furniture boards
Stone Grain	Stone-like textured finish	Decorative facades, wall cladding
Metallic / Pearl	Metallic reflective effect	High-end architectural panels, special design projects

Color Selection Guide by Application

Application	Recommended Color Series	Recommended Finish
Roofing Sheet	White, Grey, Blue, Green, Brown	Smooth / Orange Peel
Wall Cladding	White, Grey, Black, Blue, Green	Smooth / Matte
Sandwich Panel	White, Light Grey, Traffic White	Smooth
Industrial Building	Light Grey, Anthracite Grey, Sky Blue	Semi-Gloss / Low Gloss
Agricultural Building	Moss Green, Oxide Red, Sky Blue	Orange Peel
Residential / Villa Panel	Brown, Green, White, Beige	Smooth / Matte
Decoration Panel	White, Black, Grey, Wood Grain	Smooth / Wood Grain
Equipment Shell	White, Grey, Blue, Orange	High Gloss / Smooth

Important Notes for Color Ordering

Confirm the color standard**: Please specify RAL number, Pantone number or physical sample.

Check gloss requirement**: The same color will look different under high gloss, semi-gloss or matte finish.

Coating system matters**: PE, SMP, HDP and PVDF may affect final color appearance and weather resistance.

Color difference exists**: There may be slight color variation between different batches and between screen display and actual steel sheet.

Pre-production confirmation**: We recommend confirming a physical color swatch or trial sample before mass production.

Project specific colors**: For architectural projects, color grouping and color separation requirements should be confirmed in advance.

Product Comparison Table

Coating Grade	Best For	Pros	Limitation	Price Level
PE	Inland warehouse, simple roof, budget project	Low cost, easy forming, rich colors	Faster fading under strong UV	Low
SMP	Sunny inland building, agricultural roof	Good heat resistance, better gloss retention	Not suitable for coastal salt area	Medium
HDP	Commercial facade, medium warranty project	Great UV resistance, balanced cost & lifespan	Not recommended for severe coastal environment	Medium-High
PVDF	Coastal building, premium curtain wall, high corrosive site	Outstanding salt spray & anti-fading	Less flexible, higher cost	High

App Market

Reliable Steel Coil Solutions For Diverse Industrial Applications

Industrial Factory Panels PPGI Steel

Cold Storage Panels PPGI Steel

Rolling Shutters PPGI Steel

Container Sheets PPGI Steel

Product Packaging

Secure Export Packaging For Safe Handling And Delivery

FAQs

How to select the suitable coating grade between PE, SMP, HDP and PVDF for my project?

You can choose based on local climate, project warranty and budget. PE for normal inland low-budget jobs; SMP for sunny inland areas; HDP for commercial facades; PVDF for coastal & high-corrosion environments. Share your project location, we can give professional recommendation.

What is the MOQ if I mix different coating grades in one container?

Standard MOQ for each coating grade is 5 tons. Mixed grades in one 20ft/40ft container is acceptable, subject to our production schedule.

Can you provide paint sample swatches before mass production?

Yes, free A4 paint samples can be sent for your confirmation before production. For large orders, pre-production panel samples can also be arranged.

What is your production lead time for HDP and PVDF prepainted steel sheet?

Standard PE & SMP: 7–15 working days. HDP & PVDF require 15–25 working days due to strict coating baking and quality testing.

What kind of inspection can you support for PPGI / PPGL with these four coating grades?

We support SGS, BV or other third-party inspection at our factory. We can test coating thickness, adhesion, salt spray and color difference as your request.

Is there extra cost if I need special surface texture like wood grain for PVDF coating?

Yes. Special textures (wood grain, marble, wrinkle) will have extra production cost and slightly longer lead time, we will quote separately after receiving your detailed requirements.
