RAL Custom Colors Prepainted Steel Sheet PPGI PPGL | RAL Color Coated Metal Sheet For Roof & Facade

Full RAL Classic color library, stable color batch consistency for large projects
Accept custom color matching by physical sample or Pantone reference
Compatible with PE, SMP, HDP, PVDF coating systems for different environments
Visual color confirmation sample available before mass manufacturing
Can produce smooth, matte, wrinkle and patterned finishes with RAL colors

Product Overview

RAL Custom Colors Prepainted Steel Sheet (PPGI / PPGL) refers to color coated steel sheet produced strictly according to RAL classic color system, widely recognized by architects, contractors and metal building buyers globally. Besides standard RAL codes, we also provide custom color matching service when clients provide physical color chips or reference samples.

The substrate options are hot-dip galvanized PPGI and galvalume PPGL. Buyers can pair any RAL / custom color with PE, SMP, HDP or PVDF coating grade, to combine target color appearance and required weather resistance. Popular RAL colors include RAL9002, RAL9003, RAL7016, RAL3005, RAL5010, RAL6005. Matte, glossy, wrinkle, wood grain and marble textures are available upon request.

Our factory controls color difference strictly during coil coating process. Pre-production color swatches and test panels are supplied for client approval to avoid color deviation on bulk shipment. These RAL custom color sheets are widely used for building roofing, wall cladding, prefabricated housing, curtain wall, garage doors, container housing and decorative metal panels. All sheets adopt export seaworthy packaging, with waterproof wrapping and steel protectors to prevent scratch and color damage during long sea transit. We support different thickness, width, zinc layer and paint thickness customization for international construction projects.

Prepainted Steel Sheet - PPGI/PPGL

Chemical & Mechanical Property Snapshot

Item	Parameter
Color System	Full RAL Classic series + Custom color matching
Available Coating	PE / SMP / HDP / PVDF
Color Difference Control	ΔE ≤ 2 (factory standard)
Top Paint Thickness	15–35μm (depends on coating grade)
Substrate	PPGI DX51D+Z / PPGL DX51D+AZ
Surface Texture	Glossy, Matte, Wrinkle, Wood Grain, Marble

Detailed Technical Specifications

Item	Specification
Product Name	RAL Custom Colors Prepainted Steel Sheet PPGI PPGL
Base Material	Hot dip galvanized (PPGI), Hot dip galvalume (PPGL)
Thickness	0.12mm ~1.2mm
Width	600–1250mm, custom slit width
Zinc / Al-Z coating	Z40-Z275 g/m², AZ50-AZ150 g/m²
Paint System	2/1 or 2/2 coating
Color	All RAL Classic codes, custom color matching
Coating Option	PE, SMP, HDP, PVDF
Standard	EN10169, ASTM A755, JIS G3312
Application	Roofing, wall panel, facade, prefab house, metal decoration
Inspection	SGS, BV, factory mill test certificate

Quality Documents	Mill Test Certificate, third-party inspection optional
MOQ	Custom color MOQ negotiable
Payment Terms	T/T, L/C at Sight
Delivery Time	7–15 working days after deposit
Package	Waterproof paper + plastic film + wooden pallet, seaworthy export packing

Available Colors & Finishes – Prepainted Steel Sheet PPGI / PPGL

We offer prepainted steel sheet (PPGI) and prepainted galvanized steel sheet (PPGL) in a wide range of standard colors, gloss levels and surface finishes. Colors can be selected according to RAL standards, and custom color matching is available for special project requirements. Color consistency is controlled during coating, curing and inspection to reduce chromatic aberration in mass production.

Popular Standard Colors for PPGI / PPGL

Color Family	RAL Code	Color Name	Common Applications
White	RAL 9010	Pure White	Roofing, wall panels, clean rooms, appliances
White	RAL 9016	Traffic White	Building facades, sandwich panels, interior panels
White	RAL 9003	Signal White	Decoration panels, equipment shells, lightweight panels
Grey	RAL 7035	Light Grey	Industrial buildings, warehouses, partition panels
Grey	RAL 7016	Anthracite Grey	Modern facades, trim panels, architectural profiles
Grey	RAL 7004	Signal Grey	Steel structure buildings, workshops, silos
Grey	RAL 7024	Graphite Grey	Heavy industrial buildings, equipment enclosures
Black	RAL 9005	Jet Black	Facade trim, edge panels, decorative profiles
Black	RAL 9017	Traffic Black	Industrial cladding, structural parts
Blue	RAL 5015	Sky Blue	Industrial roofs, workshop walls, agricultural buildings
Blue	RAL 5010	Gentian Blue	Factories, warehouses, steel structure buildings
Blue	RAL 5005	Signal Blue	Cladding panels, equipment covers
Red	RAL 3009	Oxide Red	Agricultural buildings, roof sheets, warning parts
Red	RAL 3020	Traffic Red	Warning panels, architectural trim
Red	RAL 3011	Brown Red	Industrial buildings, special profiles
Green	RAL 6005	Moss Green	Farm buildings, garden enclosures, rural roofs
Green	RAL 6018	Yellow Green	Decorative panels, landscape buildings
Green	RAL 6029	Mint Green	Interior panels, appliance panels
Brown	RAL 8017	Chocolate Brown	Residential roofs, villa panels, decorative facades
Brown	RAL 8004	Copper Brown	Industrial buildings, roof systems
Beige / Cream	RAL 1015	Light Ivory	Interior panels, ceilings, decorative profiles
Beige / Cream	RAL 1001	Beige	Building facades, housing projects
Orange	RAL 2004	Pure Orange	Warning cladding, equipment panels
Yellow	RAL 1023	Traffic Yellow	Warning parts, safety-related panels

Gloss Level Options

Gloss Type	Gloss Range	Description	Recommended Applications
High Gloss	≥ 70°	Bright surface, strong reflection	Appliance panels, furniture boards, indoor decoration
Semi-Gloss	40°–70°	Balanced shine, good appearance	General roofing, wall cladding, steel structure buildings
Low Gloss	20°–40°	Soft reflection, less glare	Facades, industrial buildings, noise reduction panels
Matte	< 20°	Very low reflection, modern look	Architectural panels, premium facade projects

Surface Finish Options

Finish Type	Description	Recommended Applications
Smooth	Smooth painted surface with a clean appearance	Roofing sheets, wall panels, sandwich panels
Matte Finish	Low-gloss, anti-glare surface with a modern visual effect	Building facades, industrial cladding
Orange Peel	Fine textured surface that helps hide minor scratches	Bending profiles, roofing, general construction
Wood Grain	Decorative wood imitation pattern	Interior panels, doors, furniture boards
Stone Grain	Stone-like textured finish	Decorative facades, wall cladding
Metallic / Pearl	Metallic reflective effect	High-end architectural panels, special design projects

Color Selection Guide by Application

Application	Recommended Color Series	Recommended Finish
Roofing Sheet	White, Grey, Blue, Green, Brown	Smooth / Orange Peel
Wall Cladding	White, Grey, Black, Blue, Green	Smooth / Matte
Sandwich Panel	White, Light Grey, Traffic White	Smooth
Industrial Building	Light Grey, Anthracite Grey, Sky Blue	Semi-Gloss / Low Gloss
Agricultural Building	Moss Green, Oxide Red, Sky Blue	Orange Peel
Residential / Villa Panel	Brown, Green, White, Beige	Smooth / Matte
Decoration Panel	White, Black, Grey, Wood Grain	Smooth / Wood Grain
Equipment Shell	White, Grey, Blue, Orange	High Gloss / Smooth

Important Notes for Color Ordering

Confirm the color standard**: Please specify RAL number, Pantone number or physical sample.

Check gloss requirement**: The same color will look different under high gloss, semi-gloss or matte finish.

Coating system matters**: PE, SMP, HDP and PVDF may affect final color appearance and weather resistance.

Color difference exists**: There may be slight color variation between different batches and between screen display and actual steel sheet.

Pre-production confirmation**: We recommend confirming a physical color swatch or trial sample before mass production.

Project specific colors**: For architectural projects, color grouping and color separation requirements should be confirmed in advance.

Product Comparison Table

Type	Color Source	Color Consistency	MOQ	Recommended Scenario
Standard RAL Color	RAL Classic official color card	High, stable batch to batch	5 tons	Large commercial building, repeated orders
Custom Matched Color	Customer physical sample / Pantone	Depends on reference sample	10 tons	Unique design project, special architectural requirement

App Market

Reliable Steel Coil Solutions For Diverse Industrial Applications

Industrial Factory Panels PPGI Steel

Cold Storage Panels PPGI Steel

Rolling Shutters PPGI Steel

Container Sheets PPGI Steel

Product Packaging

Secure Export Packaging For Safe Handling And Delivery

FAQs

Can I confirm RAL color via screen picture only before order?

Screen display will have color deviation. We suggest confirming by physical color swatch or pre-production panel to avoid difference after mass production.

What is the MOQ for non-standard custom matched color PPGI sheet?

Standard RAL colors MOQ is 5 tons. Custom matched colors require minimum 10 tons per color due to paint mixing setup.

How long is lead time for custom RAL color prepainted steel sheet?

Popular standard RAL colors: 7–15 working days. New custom color matching needs extra time for paint formulation, total lead time 15–25 working days.

Can I combine multiple different RAL colors into one container shipment?

Yes, multiple RAL colors can be mixed in one container, each color meets its own MOQ requirement.

What causes color difference between batches for RAL PPGI sheet?

Raw paint batch variation, curing temperature and light viewing angle may cause minor difference. Our factory controls ΔE ≤2 to guarantee consistency for construction projects.

Is RAL color coating scratch resistant during roll forming?

The coating has good flexibility for normal bending and corrugation. But sharp scratches during transportation or processing will damage the paint layer, we suggest protective film if you have strict surface requirements.
