TDC51D+AZ PPGL Prepainted Aluzinc Steel Sheet | Color Coated GL Plate
- TDC51D+AZ aluzinc substrate, superior salt spray resistance for coastal humid areas
- 55% Al-Zn alloy base outperforms GI substrate in long-term anti-corrosion performance
- 2/1 & 2/2 coating structure, PE/SMP/HDP/PVDF paint for multi-environment selection
- Wide RAL color range, custom gloss & texture finish for architectural facade design
- Good formability, stable paint adhesion for bending, profiling and panel fabrication
Contact Us
Product Overview
TDC51D+AZ PPGL Prepainted Aluzinc Steel Sheet (Color Coated GL Plate) uses TDC51D+AZ aluzinc (GL) steel as substrate. The substrate adopts 55% aluminum-zinc-silicon hot dip alloy coating, delivering excellent anti-corrosion performance especially in coastal, salt fog and high humidity atmosphere.
TDC51D+AZ grade has balanced ductility and corrosion resistance. The prepainted organic coating can be PE, SMP, HDP, PVDF. Coating structure optional 2/1 (top coat + primer) or 2/2 (top + primer on both sides). It supports full RAL color system, custom color matching, gloss adjustment and various surface textures including smooth, orange peel, wood grain and stone grain.
TDC51D+AZ PPGL is the preferred material for seaside factory roofing, wall cladding, cold storage panels, container side panels, coastal agricultural greenhouses and high humidity building facades.
Available thickness: 0.20mm–1.2mm; Width:700–1250mm, supplied in coil or cut flat sheet. Aluzinc coating weight: AZ50, AZ70, AZ100, AZ150.
Chemical & Mechanical Property Snapshot
Detailed Technical Specifications
Available Colors & Finishes – Prepainted Steel Sheet PPGI / PPGL
Popular Standard Colors for PPGI / PPGL
Gloss Level Options
Surface Finish Options
Color Selection Guide by Application
Product Comparison Table
App Market
Reliable Steel Coil Solutions For Diverse Industrial Applications
Industrial Factory Panels PPGI Steel
Cold Storage Panels PPGI Steel
Rolling Shutters PPGI Steel
Container Sheets PPGI Steel
Product Packaging
Secure Export Packaging For Safe Handling And Delivery
FAQs
PPGL uses aluzinc GL substrate, much better salt spray resistance for coastal areas. PPGI uses galvanized GI substrate for inland regular projects.
AZ100 is standard for coastal; AZ150 is suggested for strong salt fog environment to extend service life.
Yes, TDC51D+AZ PPGL has outstanding humidity and corrosion resistance, widely applied for cold storage cladding panels.
Yes, we support RAL color selection and custom color matching, physical color swatch can be sent before production.
Yes, TDC51D+AZ has good forming performance. The coating can keep integrity during roll forming operation.
MTC, packing list, commercial invoice, bill of lading. SGS/BV third-party inspection can be arranged upon request
